Torlon® 4203 Polyamide-imide Sheet
Torlon® 4203 Polyamide-imide Sheet
SKU:SHA-c790f8
Torlon® 4203 PAI Sheet: Unrivaled strength & durability for high-temp applications. Brown/yellow, 1.00in thick, ideal for electrical connectors & chip nests.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
Torlon® 4203 Polyamide-imide Sheet
$149.99
Quantity: 1
Claim Your Seller Account
Torlon® 4203 Polyamide-imide Sheet
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience unparalleled strength and durability with Torlon® 4203 PAI Sheet. Designed to withstand extreme thermal and chemical conditions, this brown/yellow sheet excels in high temperature electrical connectors, chip nests, and sockets. With a tensile strength of 20000 psi, flexural modulus of 600000 psi, and a heat deflection temperature of 532 ºF, this sheet guarantees lasting performance in the most demanding environments. Trust Torlon® 4203 for unmatched reliability and endurance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Applications
High temperature electrical connectors.Chip nests & sockets.Can mandrel
Characteristics Characteristics
Maintains strength & stiffness to 500ºF.Minimal expansion rate to 500ºF.Able to endure harsh thermal, chemical and stress conditions.
Specifications Availability
3-5 days
Specifications Coefficient Of Friction Static
0.35
Specifications Color
Brown/Yellow
Specifications Compressive Modulus
479000 psi
Specifications Compressive Strength
23900 psi
Specifications Dielectric Strength
580 V/mil
Specifications Flammability At 125 Ul94
V0
Specifications Flexural Modulus
600000 psi
Specifications Flexural Strength
23900 psi
Specifications Glass Transition Temperature
527 ºF
Specifications Hardness Rockwell
E80 / M120
Specifications Heat Deflection Temperature 264 Psi
532 ºF
Specifications Izod Impact Strength Notched Astm D256
2.0
Specifications Material
PAI
Specifications Minimum Order
1
Specifications Optional Sheet Size
12 x 48
Specifications Sheet Size
12 x 12 in
Specifications Specific Gravity
1.41
Specifications Tensile Elongation Break
10%
Specifications Tensile Modulus
600000 psi
Specifications Tensile Strength
20000 psi
Specifications Thickness
1.00 in
Specifications Tolerance
+only in
Specifications Water Absorption 24 Hrs
0.40 %
Specifications Water Absorption Saturation Astm D570
1.70
Specifications Weight
7.33 lb/ft²
