Torlon® 4203 Polyamide-imide Sheet
Torlon® 4203 Polyamide-imide Sheet
SKU:SHA-19681b
Torlon® 4203 PAI Sheet - Superior strength & thermal resistance up to 500ºF for demanding applications.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Torlon® 4203 Polyamide-imide Sheet
$129.99
Quantity: 1
Claim Your Seller Account
Torlon® 4203 Polyamide-imide Sheet
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience exceptional performance with our Torlon® 4203 Polyamide-imide Sheet. This brown/yellow sheet boasts a thickness of 0.750 in, offering superior strength, stiffness, and minimal expansion up to 500ºF. With a plethora of impressive attributes like high tensile and flexural strength, excellent thermal and chemical resistance, and a Rockwell hardness rating of E80/M120, this sheet is perfect for high temperature electrical connectors, chip nests & sockets, and other demanding applications. Meet your requirements for durability and reliability with this top-notch PAI sheet.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Applications
High temperature electrical connectors.Chip nests & sockets.Can mandrel
Characteristics Characteristics
Maintains strength & stiffness to 500ºF.Minimal expansion rate to 500ºF.Able to endure harsh thermal, chemical and stress conditions.
Specifications Availability
3-5 days
Specifications Coefficient Of Friction Static
0.35
Specifications Color
Brown/Yellow
Specifications Compressive Modulus
479000 psi
Specifications Compressive Strength
23900 psi
Specifications Dielectric Strength
580 V/mil
Specifications Flammability At 125 Ul94
V0
Specifications Flexural Modulus
600000 psi
Specifications Flexural Strength
23900 psi
Specifications Glass Transition Temperature
527 ºF
Specifications Hardness Rockwell
E80 / M120
Specifications Heat Deflection Temperature 264 Psi
532 ºF
Specifications Izod Impact Strength Notched Astm D256
2.0
Specifications Material
PAI
Specifications Minimum Order
1
Specifications Optional Sheet Size
12 x 48
Specifications Sheet Size
12 x 12 in
Specifications Specific Gravity
1.41
Specifications Tensile Elongation Break
10%
Specifications Tensile Modulus
600000 psi
Specifications Tensile Strength
20000 psi
Specifications Thickness
0.750 in
Specifications Tolerance
+only in
Specifications Water Absorption 24 Hrs
0.40 %
Specifications Water Absorption Saturation Astm D570
1.70
Specifications Weight
5.50 lb/ft²
