TPR 203mm Self-Piercing Rivet
TPR 203mm Self-Piercing Rivet
SKU:TPR-147822
Discover the durable TPR Self-Piercing Rivet - Strong, Reliable, and Precise. Ideal for Industrial Applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
TPR 203mm Self-Piercing Rivet
$29.99
Quantity: 1
Claim Your Seller Account
TPR 203mm Self-Piercing Rivet
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The TPR 203mm Self-Piercing Rivet is a high-quality fastening solution designed for a wide range of applications. Made of Aluminum Alloy with a Zinc Coated Chromium Mandrel, this rivet offers exceptional durability and corrosion resistance. With a grip range of 167.0mm to 184.0mm and shear force of 250 kgf, it ensures strong and reliable connections. Ideal for industrial, automotive, and aerospace uses, this rivet meets stringent government procurement standards like FAR compliance and is trusted for its precision and performance.
Product Specifications
Nominal Dimensions Body Length
203.0 mm | 8.0 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.8 to 7.0 mm | 0.268 to 0.276 in
Nominal Dimensions Head Diameter
12.0 mm | 0.472 in
Nominal Dimensions Head Thickness
1.80 mm | 0.071 in
Nominal Dimensions Mandrel Diameter
3.6 mm | 0.142 in
Nominal Dimensions Maximum Grip Range
184.0 mm | 7.244 in
Nominal Dimensions Minimum Grip Range
167.0 mm | 6.574 in
Nominal Forces Nominal Shear Force
250 kgf | 551 lbf
Nominal Forces Nominal Tensile Force
320 kgf | 706 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 3.0/5.0)
Technical Specs Brands
Ornit | TPR
Technical Specs Carton Quantity
250
Technical Specs Mandrel Finish
Zinc Coated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
