TPR Self-Piercing Rivet - 253.0mm Body Length, Aluminum Alloy, Zinc Coated
TPR Self-Piercing Rivet - 253.0mm Body Length, Aluminum Alloy, Zinc Coated
SKU:TPR-db16d7
Get reliable and durable fastening with the TPR Self-Piercing Rivet - 253.0mm body length, Aluminum Alloy construction, and Zinc Coated finish.
Regular price
$35.99
Regular price
Sale price
$35.99
Unit price
per
Initiate Order
TPR Self-Piercing Rivet - 253.0mm Body Length, Aluminum Alloy, Zinc Coated
$35.99
Quantity: 1
Claim Your Seller Account
TPR Self-Piercing Rivet - 253.0mm Body Length, Aluminum Alloy, Zinc Coated
$35.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The TPR Self-Piercing Rivet with a body length of 253.0mm is a high-quality fastening solution ideal for a wide range of applications. Made from durable Aluminum Alloy (ALmg 3.0/5.0) with a Natural finish, this rivet ensures lasting strength and corrosion resistance. The Carbon Steel mandrel with Zinc Coated Chromium finish offers reliable performance in shear and tensile forces up to 250 kgf and 320 kgf respectively. With precise dimensions and a grip range of 218.0mm to 235.0mm, this rivet provides secure and efficient fastening in various materials.
Product Specifications
Nominal Dimensions Body Length
253.0 mm | 10.0 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.8 to 7.0 mm | 0.268 to 0.276 in
Nominal Dimensions Head Diameter
12.0 mm | 0.472 in
Nominal Dimensions Head Thickness
1.80 mm | 0.071 in
Nominal Dimensions Mandrel Diameter
3.6 mm | 0.142 in
Nominal Dimensions Maximum Grip Range
235.0 mm | 9.252 in
Nominal Dimensions Minimum Grip Range
218.0 mm | 8.582 in
Nominal Forces Nominal Shear Force
250 kgf | 551 lbf
Nominal Forces Nominal Tensile Force
320 kgf | 706 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 3.0/5.0)
Technical Specs Brands
Ornit | TPR
Technical Specs Carton Quantity
100
Technical Specs Mandrel Finish
Zinc Coated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
