Transparent 3-Pin Wire Mount Socket Connector
Transparent 3-Pin Wire Mount Socket Connector
SKU:PRO-073336
Premium 3-Pin Wire Mount Socket Connector for secure and reliable connections in diverse applications.
Regular price
$2.10
Regular price
Sale price
$2.10
Unit price
per
Initiate Order
Transparent 3-Pin Wire Mount Socket Connector
$2.10
Quantity: 1
Claim Your Seller Account
Transparent 3-Pin Wire Mount Socket Connector
$2.10
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Transparent 3-Pin Wire Mount Socket Connector is a high-quality connector designed for maximum AC/DC voltage of ~250V. It features a Terminal Material of C5210 with Gold plating, ensuring excellent conductivity. The body is made of Polycarbonate/ABS for durability and safety (UL94V-0 rated). With a maximum rated current of 3.0A and a secure terminal retention of 1.4 kgf, this Sensor Connector meets the needs of various applications. Ideal for wire sizes 30-28 AWG with a cross-sectional area of 0.05 to 0.08 mm², this connector guarantees reliable performance. Add this compliant connector to your connectivity solutions for seamless integration and reliable operations.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Transparent
Specifications Connector Type
Wire Mount Socket
Specifications Cover Color
Transparent
Specifications Cover Diameter
0.6 to 0.8 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.05 to 0.08 mm²
Specifications Number Of Pins
3
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.05 to 0.08 mm²
Specifications Wire Size
30-28 AWG
