Triad CMT8100 Common Mode Inductors
Triad CMT8100 Common Mode Inductors
SKU:IND-9eb777
Dependable CMT8100 Series Common Mode Inductors with 1.0 to 50 mH inductance, 2.4 A current, and VDE, IEC, UL, CSA compliance.
Regular price
$12.99
Regular price
Sale price
$12.99
Unit price
per
Initiate Order
Triad CMT8100 Common Mode Inductors
$12.99
Quantity: 1
Claim Your Seller Account
Triad CMT8100 Common Mode Inductors
$12.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Triad CMT8100 Series Common Mode Inductors are essential components for power supplies, effectively suppressing EMI and providing differential mode filtering. With a high inductance range of 1.0 to 50 mH, a maximum current of 2.4 A, and compliance with VDE, IEC, UL, and CSA standards, these inductors ensure minimal AC line interference. Operating temperature ranging from -55 to 105°C and RMS Dielectric Voltage Strength of 1500 V make them reliable for various applications.
Product Specifications
Specifications Dimension B 001
0.425 in
Specifications Dimension C 0015
0.600 in
Specifications Dimension D 0015
0.250 in
Specifications Inductance Range
1.0 to 50 mH
Specifications Industry Standards
CSA | IEC | UL | VDE
Specifications Maximum Dimension A
0.76 in
Specifications Maximum Dimension E
0.90 in
Specifications Maximum Dimension F
0.040 in
Specifications Max Current
2.4 A
Specifications Max Dcr
0.09 Ohm
Specifications Minimum Dimension G
0.15 in
Specifications Min Inductance L At 1 Khz
2.5 mH
Specifications Operating Temperature
-55 to 105 ºC
Specifications Rms Current Rating
1.7 to 20 A
Specifications Rms Dielectric Voltage Strength
1500 V
