The Triad CMT8100 Series Common Mode Inductors deliver exceptional Triad common mode EMI suppression, effectively eliminating noise common to all lines in various power supplies. With a minimum inductance of 4.0 mH at 1 kHz and a maximum current of 1.7 A, these inductors ensure reliable differential mode filtering. Compliant with VDE, IEC, UL, and CSA standards, they efficiently reduce AC line transmitted interference caused by high-frequency switching power supplies. Designed for durability and performance, these inductors are ideal for demanding applications.
Product Specifications
Specifications Dimension B 001
0.425 in
Specifications Dimension C 0015
0.600 in
Specifications Dimension D 0015
0.250 in
Specifications Inductance Range
1.0 to 50 mH
Specifications Industry Standards
CSA | IEC | UL | VDE
Specifications Maximum Dimension A
0.76 in
Specifications Maximum Dimension E
0.90 in
Specifications Maximum Dimension F
0.040 in
Specifications Max Current
1.7 A
Specifications Max Dcr
0.173 Ohm
Specifications Minimum Dimension G
0.15 in
Specifications Min Inductance L At 1 Khz
4.0 mH
Specifications Operating Temperature
-55 to 105 ºC
Specifications Rms Current Rating
1.7 to 20 A
Specifications Rms Dielectric Voltage Strength
1500 V
