Triad CMT8100 Series Common Mode Inductors
Triad CMT8100 Series Common Mode Inductors
SKU:IND-b43d76
Reliable EMI suppression inductors for power supplies. Compliant with VDE, IEC, UL, and CSA standards.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Triad CMT8100 Series Common Mode Inductors
$24.99
Quantity: 1
Claim Your Seller Account
Triad CMT8100 Series Common Mode Inductors
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience reliable EMI suppression with Triad CMT8100 Series Common Mode Inductors. Ideal for power supplies, these inductors eliminate common line noise and provide effective differential mode filtering. Compliant with VDE, IEC, UL, and CSA requirements, they minimize AC line interference from high frequency switching power supplies. With an inductance range of 1.0 to 50 mH, RMS current rating of 1.7 to 20 A, and operating temperature of -55 to 105°C, these inductors are precision-engineered for optimal performance.
Product Specifications
Specifications Dimension B 001
0.425 in
Specifications Dimension C 0015
0.600 in
Specifications Dimension D 0015
0.250 in
Specifications Inductance Range
1.0 to 50 mH
Specifications Industry Standards
CSA | IEC | UL | VDE
Specifications Maximum Dimension A
0.76 in
Specifications Maximum Dimension E
0.90 in
Specifications Maximum Dimension F
0.040 in
Specifications Max Current
4.8 A
Specifications Max Dcr
0.022 Ohm
Specifications Minimum Dimension G
0.15 in
Specifications Min Inductance L At 1 Khz
1.0 mH
Specifications Operating Temperature
-55 to 105 ºC
Specifications Rms Current Rating
1.7 to 20 A
Specifications Rms Dielectric Voltage Strength
1500 V
