Tungsten Carbide ANSI Grade Classifications

Name: Tungsten Carbide ANSI Grade Classifications
Brand: Ultra-Met
SKU: STA-fea813
Price: 39.99 USD
Availability: OutOfStock

SKU:STA-fea813

Premium Tungsten Carbide grades for rigorous steel machining. Achieve superior performance and longevity.

$39.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Experience exceptional durability with our Tungsten Carbide ANSI Grade Classifications. With ANSI Grades Z54 and ISO Code P50/M50, these medium-grain carbide grades are ideal for roughing cuts on steels. Featuring a nominal composition of 74.50% Tungsten Carbide, 12.50% Cobalt, and more, these inserts offer a hardness of 90.3 HRA, density of 12.94 g/cc, and a high Transverse Rupture Strength of 380 ksi. Enhance your machining operations with precision and reliability.

Product Specifications

Classifications Applications

Roughing Cuts (Machining - Steels)

Classifications Grades

Tungsten Carbide

Classifications Grain Size

Medium

Classifications Iso Code

P50/M50

Classifications Ultra Met Grades

Z54

Nominal Composition Cobalt Co

12.50%

Nominal Composition Niobium Carbide Nbc

9.00%

Nominal Composition Tantalum Carbide Ta

9.00%

Nominal Composition Titanium Carbide Tic

4.00%

Nominal Composition Tungsten Carbide Wc

74.50%

Physical Properties Density

12.94 g/cc

Physical Properties Hardness Hra

90.3 Ra

Physical Properties Transverse Rupture Trs

380 ksi | 380000 psi

Tungsten Carbide ANSI Grade Classifications
