Tungsten Carbide ANSI Grade Classifications

Name: Tungsten Carbide ANSI Grade Classifications
Brand: Ultra-Met
SKU: STA-f1a543
Price: 89.99 USD
Availability: OutOfStock

SKU:STA-f1a543

Premium Tungsten Carbide grades for precise machining of various materials. High hardness, fine grain size, and exceptional strength.

$89.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Our Tungsten Carbide ANSI Grade Classifications offer superior performance in machining cast iron, non-ferrous, and non-metallic materials. With a Cobalt content of 6.00% and Tungsten Carbide at 94.00%, these grades provide exceptional hardness at 91.8 HRA, density of 14.94 g/cc, and a Transverse Rupture Strength of 350 ksi. Ideal for general-purpose applications, these Ultra-Met Grades Z22 with ISO Code K20 and Fine Grain Size ensure precision and durability in machining tasks.

Product Specifications

Classifications Applications

General Purpose (Machining - Cast Iron, Non-Ferrous, and Non-Metalic Materials)

Classifications Grades

Tungsten Carbide

Classifications Grain Size

Fine

Classifications Iso Code

K20

Classifications Ultra Met Grades

Z22

Nominal Composition Cobalt Co

6.00%

Nominal Composition Tungsten Carbide Wc

94.00%

Physical Properties Density

14.94 g/cc

Physical Properties Hardness Hra

91.8 Ra

Physical Properties Transverse Rupture Trs

350 ksi | 350000 psi

Tungsten Carbide ANSI Grade Classifications
