Premium Tungsten Carbide grades for high-performance applications. Medium/coarse grain size, exceptional hardness, and superior strength. ANSI standard compliant.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Tungsten Carbide ANSI Grade Classifications
$99.99
Quantity: 1
Claim Your Seller Account
Tungsten Carbide ANSI Grade Classifications
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience superior performance with our Tungsten Carbide ANSI Grade Classifications. Featuring a medium/coarse grain size and a nominal composition of Cobalt (Co), Tantalum Carbide (Ta), Tungsten Carbide (WC), and Niobium Carbide (NBC), these grades offer exceptional hardness (HRA 87.8 Ra) and density (13.20 g/cc). Ideal for light cut and hot flash weld removal applications, with a Transverse Rupture Strength of 380 ksi. Meet ANSI standards for reliable quality and durability.
Product Specifications
Classifications Applications
Light Cut Hot Flash Weld Removal
Classifications Grades
Tungsten Carbide
Classifications Grain Size
Medium/Coarse
Classifications Iso Code
C15A
Classifications Ultra Met Grades
Z57
Nominal Composition Cobalt Co
14.00%
Nominal Composition Niobium Carbide Nbc
20.00%
Nominal Composition Tantalum Carbide Ta
20.00%
Nominal Composition Tungsten Carbide Wc
66.00%
Physical Properties Density
13.20 g/cc
Physical Properties Hardness Hra
87.8 Ra
Physical Properties Transverse Rupture Trs
380 ksi | 380000 psi
