Tungsten Carbide ISO Grade Classifications
Tungsten Carbide ISO Grade Classifications
SKU:STA-b89fe8
Premium Tungsten Carbide grades - Ideal for Roughing Cuts on steels. ANSI Code C5, Medium grain size, outstanding physical properties.
Regular price
$75.99
Regular price
Sale price
$75.99
Unit price
per
Initiate Order
Tungsten Carbide ISO Grade Classifications
$75.99
Quantity: 1
Claim Your Seller Account
Tungsten Carbide ISO Grade Classifications
$75.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Explore our Tungsten Carbide ISO Grade Classifications known for their premium quality and reliability. With ANSI Code C5 and a medium grain size, these grades are ideal for Roughing Cuts on steels. The nominal composition includes Cobalt (12.50%), Titanium Carbide (4.00%), Tantalum Carbide (9.00%), Tungsten Carbide (74.50%), and Niobium Carbide (9.00%). Benefit from their exceptional physical properties featuring a hardness of 90.3 HRA, density of 12.94 g/cc, and Transverse Rupture strength of 380 ksi (380000 psi).
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classifications Ansi Code
C5
Classifications Applications
Roughing Cuts (Machining - Steels)
Classifications Grades
Tungsten Carbide
Classifications Grain Size
Medium
Classifications Ultra Met Grades
Z54
Nominal Composition Cobalt Co
12.50%
Nominal Composition Niobium Carbide Nbc
9.00%
Nominal Composition Tantalum Carbide Ta
9.00%
Nominal Composition Titanium Carbide Tic
4.00%
Nominal Composition Tungsten Carbide Wc
74.50%
Physical Properties Density
12.94 g/cc
Physical Properties Hardness Hra
90.3 Ra
Physical Properties Transverse Rupture Trs
380 ksi | 380000 psi
