Turquoise Blue Female Splitter Connector (6mm Minimum Cable Diameter)
Turquoise Blue Female Splitter Connector (6mm Minimum Cable Diameter)
SKU:CIR-d9b01f
High-quality Turquoise Blue Female Splitter Connector for outdoor use, designed for 6/7 poles. cULus-Listed | IEC compliant.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Turquoise Blue Female Splitter Connector (6mm Minimum Cable Diameter)
$29.99
Quantity: 1
Claim Your Seller Account
Turquoise Blue Female Splitter Connector (6mm Minimum Cable Diameter)
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Turquoise Blue Female Splitter Connector features a screw connection, suitable for outdoor use with a minimum cable diameter of 6mm. It is designed to accommodate 6/7 poles and is cULus-Listed | IEC compliant. With a Voltage rating of 250V, 400V, 600V, and a high degree of protection (IP69), this connector ensures reliable performance in demanding environments. It meets current requirements per IEC and cURus standards, making it ideal for industrial applications.
Product Specifications
Note Note
Technical details are subject to change
Specifications Color Of Codingcontact Carrier
Turquoise Blue
Specifications Connection Type
Screw Connection
Specifications Current According To Canadian Ul Recognized Unite
3 x 16 A + 4 x 2 A (Canada) | 3 x 20 A + 4 x 5 A (USA)
Specifications Current According To International Electrotechnic
3 x 20 A + 4 x 5 A
Specifications Degree Of Protection According To Canadian Ul Rec
Type 4X/6P
Specifications Degree Of Protection According To International E
IP69
Specifications Maximum Cable Diameter
10 mm
Specifications Minimum Cable Diameter
6 mm
Specifications Model
Female
Specifications Number Of Poles
7
Specifications Standards
cULus-Listed | IEC
Specifications Voltage
250 V | 400 V | 600 V
Specifications Wire Size According To Canadian Ul Recognized Uni
20 to 14 AWG
Specifications Wire Size According To International Electrotechn
0.2 to 1.5 mm²
