TV Style Tubing Check Valve - 1/2" Line Size, 1.50 psi Standard Cracking Pressure

Name: TV Style Tubing Check Valve - 1/2" Line Size, 1.50 psi Standard Cracking Pressure
Brand: Check-All Valve Mfg. Co.
SKU: TVS-571d3a
Price: 49.99 USD
Availability: OutOfStock

SKU:TVS-571d3a

Ensure reliable backflow prevention with our TV Style Tubing Check Valve - ideal for low-pressure relief. Constructed with durable 316 Stainless Steel. Meets industry standards.

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The TV Style Tubing Check Valve offers reliable backflow prevention and low-pressure relief capabilities, ideal for a variety of applications. Constructed with durable 316 Stainless Steel and featuring compression tube fittings, this valve ensures a secure seal. With customizable seat and spring material options, it meets stringent industry standards and can be supplied with B16.34 certification, catering to institutional procurement requirements. Achieve peace of mind with the Check-All® TV valve, designed for optimal performance and longevity.

Product Specifications

Note

Consult the factory for instrumentation applications or for more information.Made in USA.

Specifications Body Material

316 Stainless Steel = SS | Brass = BR | Carbon Steel = CS

Specifications Certifications

European Conformity (CE) PED 2014/68/EU Complaint | International Organization for Standardization (ISO 9001) Certified

Specifications Line Size

1/2 in

Specifications Non Shock Pressure Rating At 100 Degree Fahrenhei

5000 psig

Specifications Note For Material

Listed above are the most common material selections. Please contact the factory for additional options.

Specifications Seat Material

Specifications Size Code

Specifications Special Options

O = Outer O-Ring Seals Same as Seat | T = FEP Encapsulated Spring

Specifications Spring Material

Specifications Standard Cracking Pressure

1.50 psi

Specifications Standard End Fitting O Ring Material

Buna-N = BN | Ethylene Propylene Diene Monomer (EPDM) = EP (EP seats not recommended for use with Carbon Steel valves.) | Fluoro-Elastomer (FKM) = VT | Neoprene = NE | Polytetrafluoroethylene (PTFE) = TF

Specifications Valve Style

TV Style Tubing Check Valve - 1/2" Line Size, 1.50 psi Standard Cracking Pressure
