TX-1100-EXR Explosion Proof Oxygen Monitor
TX-1100-EXR Explosion Proof Oxygen Monitor
SKU:OXY-658076
Ensure safety in hazardous areas with the TX-1100-EXR Explosion Proof Oxygen Monitor - reliable, accurate, and customizable for different industrial needs.
Regular price
$1,599.99
Regular price
Sale price
$1,599.99
Unit price
per
Initiate Order
TX-1100-EXR Explosion Proof Oxygen Monitor
$1,599.99
Quantity: 1
Claim Your Seller Account
TX-1100-EXR Explosion Proof Oxygen Monitor
$1,599.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The TX-1100-EXR Explosion Proof Oxygen Monitor is designed for environments requiring Class I, Div I, Group B, C, D, and Div 2 Group E, F, G Enclosures. Engineered to prevent ignition sources, it's ideal for spaces with combustible gases like cryogenic gases and high oxygen concentrations. Featuring a 10+ year zirconium oxide sensor, it ensures accurate monitoring. With dual-level alarm relay contacts and no calibration needed, this monitor provides reliable safety in hazardous areas. Additionally, it can be customized for Class II dust configurations upon request, making it versatile for various industrial settings.
Product Specifications
Options Options
Available in Class II dust configuration.24 VDC Power Supply (P/N 45101)Horn and Strobe Combo (P/N 42002)Remote Display (P/N 99043)
Specifications Accuracy
± 1 % of Full Scale
Specifications Current
300 mA
Specifications Depth
3.25 in | 82.5 mm
Specifications Digital Display Analog Output Range
4 to 20 mA
Specifications Direct Current Dc Voltage
24 V
Specifications Display
Long life zirconium oxide sensor cell
Specifications Enclosure Material
Explosion proof Class 1, Div 1, Group B C and D
Specifications Gases Detected
Oxygen (O2)
Specifications Height
4.5 in | 114.3 mm
Specifications Operating Temperature
-40 to +55 ºC
Specifications Oxygen Range
0 to 25 %
Specifications Required Calibration
NoneNo Zero or Span Pot Adjustment Required
Specifications Sampling Method
Sample Draw
Specifications Sensor Life
10+ years under normal conditions
Specifications Signal Outputs
4-20 mA Analog Output Dual Level Alarm Relay Contacts
Specifications Weight
12 lb | 5.5 kg
Specifications Width
6.625 in | 165.1 mm
Standard Features 0
EX Class 1 Div 1 Group B,C,D, and Div 2 Group E,F, G Enclosure10 + Years No Calibration SensorTwo-Alarm Relays for 19.5% and 18.0%No Maintenance Required3 Year WarrantyLow 450ºC temperature Zirconium Oxide SensorNo Drift due to Thunderstorms or barometric pressure changesWall mounting bracketsBuilt-in Flow Sample Pump up 100 ftCE Approval
