U-Fix 4.0mm Aluminum Steel Large Head Rivet
U-Fix 4.0mm Aluminum Steel Large Head Rivet
SKU:UFI-fd57e5
Upgrade to the versatile U-Fix 4.0mm Aluminum Steel Rivet for strong, secure fastening in the main cabin. Carton of 4000 rivets.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
U-Fix 4.0mm Aluminum Steel Large Head Rivet
$149.99
Quantity: 1
Claim Your Seller Account
U-Fix 4.0mm Aluminum Steel Large Head Rivet
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your fastening solutions with the U-Fix 4.0mm Aluminum Steel Large Head Rivet. Crafted from high-quality Aluminum Alloy ALmg 2.5, this rivet offers superior grip strength with a minimum grip range of 4.0mm and a maximum grip range of 9.5mm. It meets stringent industry standards for shear and tensile forces, with a nominal shear force of 116 kgf and nominal tensile force of 170 kgf. The large head design ensures secure fastening and lasting durability, making it perfect for main cabin applications. Trust in the reliability of Ornit's craftsmanship with a carton quantity of 4000 rivets.
Product Specifications
Nominal Dimensions Body Length
12.7 mm | 0.500 in
Nominal Dimensions Diameter
4.0 mm | 5/32 in
Nominal Dimensions Drillhole Size
4.1 mm | 0.161 in
Nominal Dimensions Head Diameter
9.5 mm | 0.374 in
Nominal Dimensions Head Thickness
1.30 mm | 0.051 in
Nominal Dimensions Mandrel Diameter
2.11 mm | 2.25 mm | 0.083 in | 0.088 in
Nominal Dimensions Maximum Grip Range
9.5 mm | 0.374 in
Nominal Dimensions Minimum Grip Range
4.0 mm | 0.157 in
Nominal Forces Nominal Shear Force
116 kgf | 255 lbf
Nominal Forces Nominal Tensile Force
170 kgf | 375 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 2.5
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Head Style
Large Head
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel
