U-Fix 4.8mm Aluminum Steel Countersunk Head Rivet
U-Fix 4.8mm Aluminum Steel Countersunk Head Rivet
SKU:UFI-fcb05a
Versatile U-Fix 4.8mm Aluminum Steel Rivet for secure and reliable fastening in automotive and trailer applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
U-Fix 4.8mm Aluminum Steel Countersunk Head Rivet
$29.99
Quantity: 1
Claim Your Seller Account
U-Fix 4.8mm Aluminum Steel Countersunk Head Rivet
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The U-Fix 4.8mm Aluminum Steel 120 Degree Countersunk Head Rivet is a versatile and durable fastener suitable for various applications. Made with high-quality Aluminum Alloy ALmg 2.5 body material and Low Carbon Steel mandrel, it offers excellent multi-grip functionality. With a nominal shear force of 159 kgf and nominal tensile force of 240 kgf, this rivet ensures secure fastening. Ideal for automotive applications and trailer installations, the U-Fix rivet meets stringent quality standards, promising reliability and performance.
Product Specifications
Applications Automotive Application
The U-Fix is a highly versatile purpose-built fastener, featuring an excellent multi-grip function ideal for a variety of purposes. Commonly used to secure components within the vehicle.
Nominal Dimensions Body Length
16.9 mm | 0.665 in
Nominal Dimensions Diameter
4.8 mm | 3/16 in
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
8.7 mm | 0.343 in
Nominal Dimensions Head Thickness
1.45 mm | 0.057 in
Nominal Dimensions Mandrel Diameter
2.8 mm | 0.110 in
Nominal Dimensions Maximum Grip Range
12.7 mm | 0.500 in
Nominal Dimensions Minimum Grip Range
6.4 mm | 0.252 in
Nominal Forces Nominal Shear Force
159 kgf | 350 lbf
Nominal Forces Nominal Tensile Force
240 kgf | 528 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 2.5
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Head Style
Countersunk Head
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel
