U-Fix Aluminum Dome Rivet 3.2mm x 11.1mm
U-Fix Aluminum Dome Rivet 3.2mm x 11.1mm
SKU:UFI-900bc9
Secure fastening with U-Fix Aluminum Dome Rivet, 3.2mm x 11.1mm, high strength, easy installation, Ornit approved.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
U-Fix Aluminum Dome Rivet 3.2mm x 11.1mm
$29.99
Quantity: 1
Claim Your Seller Account
U-Fix Aluminum Dome Rivet 3.2mm x 11.1mm
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The U-Fix Aluminum Dome Rivet features a 3.2mm diameter and 11.1mm body length, making it ideal for secure fastening applications. Crafted from Aluminum Alloy ALmg 1.0 with a natural finish, this rivet offers exceptional shear and tensile strength, with a grip range between 4.0mm to 7.9mm. Its dome head design ensures a professional finish and easy installation. Trusted by Ornit, this rivet guarantees reliability and durability in every use, meeting stringent industrial standards.
Product Specifications
Nominal Dimensions Body Length
11.1 mm | 0.437 in
Nominal Dimensions Diameter
3.2 mm | 1/8 in
Nominal Dimensions Drillhole Size
3.3 mm | 0.130 in
Nominal Dimensions Head Diameter
6.4 mm | 0.252 in
Nominal Dimensions Head Thickness
0.95 mm | 0.037 in
Nominal Dimensions Mandrel Diameter
2.0 mm | 0.079 in
Nominal Dimensions Maximum Grip Range
7.9 mm | 0.311 in
Nominal Dimensions Minimum Grip Range
4.0 mm | 0.157 in
Nominal Forces Nominal Shear Force
45 kgf | 99 lbf
Nominal Forces Nominal Tensile Force
70 kgf | 154 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 1.0
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
10000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Aluminum Alloy ALmg 5.0
