U-Fix Aluminum Steel 120 Degree Countersunk Head Rivet
U-Fix Aluminum Steel 120 Degree Countersunk Head Rivet
SKU:UFI-e7370f
Versatile U-Fix Aluminum Steel Rivet for secure and reliable fastening in automotive and trailer applications. 120-degree countersunk head for a streamlined finish.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
U-Fix Aluminum Steel 120 Degree Countersunk Head Rivet
$45.99
Quantity: 1
Claim Your Seller Account
U-Fix Aluminum Steel 120 Degree Countersunk Head Rivet
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The U-Fix Aluminum Steel 120 Degree Countersunk Head Rivet is a versatile and purpose-built fastening solution perfect for a range of applications in the automotive industry and trailers. Featuring a durable Aluminum Alloy ALmg 2.5 body and Low Carbon Steel mandrel, it offers exceptional multi-grip functionality with a grip range of 3.2mm to 7.9mm. With a nominal shear force of 159 kgf and nominal tensile force of 240 kgf, this rivet ensures secure and reliable fastening. Its 120-degree countersunk head provides a streamlined finish. Meet your fastening needs with precision and efficiency using the U-Fix rivet.
Product Specifications
Applications Automotive Application
The U-Fix is a highly versatile purpose-built fastener, featuring an excellent multi-grip function ideal for a variety of purposes. Commonly used to secure components within the vehicle.
Nominal Dimensions Body Length
12.1 mm | 0.476 in
Nominal Dimensions Diameter
4.8 mm | 3/16 in
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
8.7 mm | 0.343 in
Nominal Dimensions Head Thickness
1.45 mm | 0.057 in
Nominal Dimensions Mandrel Diameter
2.8 mm | 0.110 in
Nominal Dimensions Maximum Grip Range
7.9 mm | 0.311 in
Nominal Dimensions Minimum Grip Range
3.2 mm | 0.126 in
Nominal Forces Nominal Shear Force
159 kgf | 350 lbf
Nominal Forces Nominal Tensile Force
240 kgf | 528 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 2.5
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
5000
Technical Specs Head Style
Countersunk Head
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel
