The UL 94V0 Castable Heat Sink Epoxy Compound in the PC-140 MT FR product line offers exceptional thermal conductivity and Class F operating properties once cured. With a high Flexural Strength of 13,500 psi and UL 94V0 approval, this epoxy compound is perfect for applications demanding reliability and performance. Its precise mix ratio, rapid curing, and robust physical properties make it a top choice for heat dissipation in various industrial settings.
Product Specifications
Cure Schedule 0
Fast Cure - 2 hours at 120 °C.Small Mass - 95 °C for 2-3 hours + 1 hour @ 120 °CLarge Mass (> 5 LBS) - 65 °C for 4 hours + 2 hours @ 120 °CPost Cure: 4 hours at 155 °C
Properties Cured Coefficient Of Thermal Expansion
26 x 106 (Part B PC 110B)
Properties Cured Dielectric Constant According To American Socie
6.3
Properties Cured Dielectric Frequency According To American Soci
60 Hz
Properties Cured Dissipation Frequency According To American Soc
60 Hz
Properties Cured Heat Distortion Point
155 ºC
Properties Cured Service Temperature Range
-55 to 155 ºC
Properties Cured Thermal Conductivity
20 BTU-in/(ft2)(hr)(°F)
Properties Cured Volume Resistivity
1.0 x 1015 ohm-cm
Properties Uncured Mix Ratio By Weight
100: 3 to 4
Properties Uncured Pot Life At 72 F
1 h
Properties Uncured Viscosity Cps American Society For Testing An
500 (Part A) | 250,000 (Part B: PC 90)
Specifications Compressive Strength According To American Societ
18,000 psi
Specifications Dielectric Strength According To American Society
420 V/mil
Specifications Dissipation Factor According To American Society
0.015
Specifications Flexural Strength According To American Society F
13,500 psi
Specifications Mixed Viscosity
40,000 cps | 50000 cps (Part B PC 110B)
Specifications Shelf Life At 72 F
12 m
Specifications Shore D Hardness According To American Society Fo
90 duro
Specifications Specific Gravity
0.96 | 0.96 (Part B: PC (90) | 2.60 | 2.60 (Part A)
Specifications Standards
UL 94V0
Specifications Tensile Elongation According To American Society
0 to 1 %
Specifications Tensile Strength According To American Society Fo
8500 psi
Specifications Type
Thermally Conductive Epoxies
Specifications Viscosity According To American Society For Testi
500 cps | 250000 cps
Use Instructions 0
Premix material in the original container prior to use to insure any settled filler may be reincorporated. Weigh out the required amount of PC 140 MT FR. Measure out the appropriate amount of material (Part A and Part B) Mix thoroughly, scraping both sides and bottom of container. Evacuate mixture at 29 in. Hg for 5- 10 minutes. Pour into mold or cavity.
