UL94V-0 Nylon Screw with .156 Board Hole x #6 - 10 Series

Name: UL94V-0 Nylon Screw with .156 Board Hole x #6 - 10 Series
Brand: All Electronics Hardware
SKU: 01C-fb19ba
Price: 24.99 USD
Availability: OutOfStock

SKU:01C-fb19ba

UL94V-0 Nylon Screw - Ideal for limited space applications, easy to install, and ASTM certified.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The UL94V-0 Nylon Screw from the 10 Series is designed for easy hand installation to chassis using self-tapping technology, making it ideal for applications with limited space. Its minimal protrusion ensures a sleek finish, and the releasable PC board mount end adds versatility. This screw is crafted from durable UL94V-0 Nylon 66, providing strength and reliability. Certified to meet ASTM D 4066 and PA111 standards, RoHS compliant, and with a temperature range of -40 to 185F (-40 to 85C), this screw is a dependable choice for circuit board supports in various settings.

Product Specifications

Specifications Board Hole Diameter

.156 (4.0) inches (mm)

Specifications Chassis Thickness

.063 (1.6) inches (mm)

Specifications Color

White

Specifications Dim L

.875 (22.2) inches (mm)

Specifications Material Code

UL94V-0
