ULTEM® 1000 - Natural Polyetherimide Sheet, 12x12 in, 1.000 in Thickness

ULTEM® 1000 - Natural Polyetherimide Sheet, 12x12 in, 1.000 in Thickness

SHA-7f3dac

ULTEM® 1000 - High-performance Polyetherimide Sheet for diverse industrial applications. Exceptional strength, chemical resistance, and FDA compliance.

$29.99
$29.99
Sale

Initiate Order

ULTEM® 1000 - Natural Polyetherimide Sheet, 12x12 in, 1.000 in Thickness

ULTEM® 1000 - Natural Polyetherimide Sheet, 12x12 in, 1.000 in Thickness

$29.99

Quantity: 1

Claim Your Seller Account

ULTEM® 1000 - Natural Polyetherimide Sheet, 12x12 in, 1.000 in Thickness

ULTEM® 1000 - Natural Polyetherimide Sheet, 12x12 in, 1.000 in Thickness

$29.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
Experience the exceptional performance of ULTEM® 1000 - Unfilled Polyetherimide Sheet. This amorphous thermoplastic material offers high strength at elevated temperatures, broad chemical resistance, and flame resistance with low smoke emission. With characteristics like superior mechanical strength and high dielectric stability, this ULTEM® PEI sheet is ideal for various applications in automotive, medical, and electrical industries. Meet diverse industrial needs with a material that excels in durability, thermal resistance, and FDA compliance.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Advantages 0
UL94 V-O.Extremely Low NBS Smoke Evolution.FDA Compliant (Natural Un-filled).Superior Limiting Oxygen Index.Broad Chemical Resistance.High Dielectric Strength & Stability.Exceptional Mechanical Strength.
Applications 0
Burn-in Test Sockets Connectors Automotive Components Valves Electrical Fittings Microwave Components Medical Components
Specifications Coefficient Of Linear Thermal Expansion
3.1 x 10-5 in/in/ºF
Specifications Compressive Modulus
480000 psi
Specifications Compressive Strength At Yield 73f Astm D695
21900 psi
Specifications Deflection Temperature At 264 Psi 0250 Astm D648
392 ºF
Specifications Deflection Temperature At 66 Psi 0250 Astm D648
410 ºF
Specifications Dielectric Strength In Air Astm D149
831 V/m
Specifications Dielectric Strength In Oil Astm D149
710 V/m
Specifications Elongation At Break 73f Astm D638
60 %
Specifications Elongation Yield 73f Astm D638
7 %
Specifications Flammability Rating Ul 94
V0
Specifications Flexural Modulus 482f250c
480000 psi
Specifications Flexural Strength 73f Astm D790
22000 psi
Specifications Hardness Rockwell Astm D785
M109
Specifications Impact Strength Notched At 73f Astm D256
1 ft·lb/in
Specifications Impact Strength Un Notched
25 ft·lb/in
Specifications Maximum Operating Temperature
338 ºF
Specifications Shear Strength Ultimate 73f
15000 psi
Specifications Sheet Size
12 x 12 in
Specifications Specific Gravity Astm D792
1.27
Specifications Tensile Modulus 73f Astm D638
430000 psi
Specifications Tensile Strength At Break 73f
15200 psi
Specifications Tensile Strength At Yield 73f Astm D638
15200 psi
Specifications Thickness
1.000 in
Specifications Volume Resistivity 0062 Astm D257
1.0 x 1017 ohm·cm
Specifications Water Absorption 24 Hrs 73f Astm D570
0.25 %
Specifications Water Absorption Equilibrium 73f Astm D570
1.25 %
Specifications Weight
6.61 lb/ft²
