Ultra-Compact ML25 Multi-Turn Rotary Position Sensors - 6 to 100 Revolutions
Ultra-Compact ML25 Multi-Turn Rotary Position Sensors - 6 to 100 Revolutions
SKU:MLS-e6a641
Experience precision and durability with our ultra-compact ML25 Multi-Turn Rotary Position Sensors. Ideal for industrial applications.
Regular price
$159.99
Regular price
Sale price
$159.99
Unit price
per
Initiate Order
Ultra-Compact ML25 Multi-Turn Rotary Position Sensors - 6 to 100 Revolutions
$159.99
Quantity: 1
Claim Your Seller Account
Ultra-Compact ML25 Multi-Turn Rotary Position Sensors - 6 to 100 Revolutions
$159.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The ML25 Series Multi-Turn Rotary Position Sensors from Novotechnik provide exceptional precision and durability for industrial applications. With a housing profile of 13 x 13 mm and up to 100 revolutions, these sensors offer superior linearity, high resolution exceeding 0.1%, and a mechanical travel of 9000º. The anodized aluminum housing, sinter bronze sleeve bearings, and conductive plastic resistance element ensure reliability in demanding environments. These sensors are designed with a precious metal wiper assembly, meeting stringent quality standards for accuracy and longevity.
Product Specifications
Specifications Actual Electrical Travel
8280 º
Specifications Available Resistance Values
10 kO
Specifications Bearings
Sinter bronze sleeve bearings
Specifications Dielectric Strength Ac 50 Hz 1 Min 1 Bar
750 V
Specifications Dimension A
77.2 mm
Specifications Dimension B
56.7 mm
Specifications Dynamic Permitted Shaft Loading Axial And Radial
1 N
Specifications Electrical Connection
Cable 1 m CRTH 3 x 0.055 mm²
Specifications Housing Material
Anodized Aluminum
Specifications Independent Linearity
0.25 %
Specifications Insulation Resistance 500 Vdc 1 Bar 2 S
= 10,000 MO
Specifications Life
> 15x106 Movements
Specifications Maximum Operational Speed
300 rpm
Specifications Maximum Permissible Applied Voltage
35 V
Specifications Maximum Wiper Current In Case Of Malfunction
5 µA
Specifications Mechanical Travel
9000 º
Specifications Mounting
Nut M10 x 0.75 and serrated washer 3/8”
Specifications Protection Class Din 40050
IP 65
Specifications Recommended Operating Wiper Current
= 1 µA
Specifications Repeatability
0.04 (=3.32º) %
Specifications Resistance Element
Conductive Plastic
Specifications Resistance Tolerance
20 %
Specifications Shaft
Brass | Nickel plated
Specifications Shock Iec 68000 2 27
30 g | 7 ms
Specifications Size
Housing profile 13 x 13 mm
Specifications Special Features
Very small dimensions | 6 - 100 revolutions | Up to 15 x 106 movements | Excellent linearity | High resolution – better than 0.1%
Specifications Static Permitted Shaft Loading Axial And Radial
1 N
Specifications Temperature Range
-25 to 75 º C
Specifications Torque
= 1 N·cm
Specifications Effective Temperature Coefficient Of The
5 ppm/K
Specifications Vibration
30 to 2000 Hz | Amax = 0.75 mm | amax = 10
Specifications Weight
31 g
Specifications Wiper Assembly
Precious Metal multi-finger wiper
