Ultra-Compact ML50 Series Rotary Position Sensors
Ultra-Compact ML50 Series Rotary Position Sensors
SKU:MLS-5bde2b
Achieve precise position sensing with Novotechnik's ML50 Series Rotary Position Sensors - ultra-compact, highly accurate, and durable for Industrial use.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Ultra-Compact ML50 Series Rotary Position Sensors
$129.99
Quantity: 1
Claim Your Seller Account
Ultra-Compact ML50 Series Rotary Position Sensors
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance precision and reliability in position sensing with the ML50 Series Multi-Turn Rotary Position Sensors by Novotechnik. Featuring an ultra-compact 13mm housing profile and offering up to 100 revolutions, these sensors deliver outstanding performance with excellent linearity and high resolution better than 0.1%. With a durable anodized aluminum housing, brass nickel-plated shaft, and sinter bronze sleeve bearings, the ML50 Series ensures longevity and accuracy in varied industrial environments. The sensors meet rigorous industry standards for resistance values, repeatability, and operational reliability, making them ideal for applications requiring utmost precision and durability.
Product Specifications
Specifications Actual Electrical Travel
17280 º
Specifications Available Resistance Values
10 kO
Specifications Bearings
Sinter bronze sleeve bearings
Specifications Dielectric Strength Ac 50 Hz 1 Min 1 Bar
750 V
Specifications Dimension A
102.2 mm
Specifications Dimension B
81.7 mm
Specifications Dynamic Permitted Shaft Loading Axial And Radial
1 N
Specifications Electrical Connection
Cable 1 m CRTH 3 x 0.055 mm²
Specifications Housing Material
Anodized Aluminum
Specifications Independent Linearity
0.25 %
Specifications Insulation Resistance 500 Vdc 1 Bar 2 S
= 10,000 MO
Specifications Life
> 15x106 Movements
Specifications Maximum Operational Speed
300 rpm
Specifications Maximum Permissible Applied Voltage
35 V
Specifications Maximum Wiper Current In Case Of Malfunction
5 µA
Specifications Mechanical Travel
18000 º
Specifications Mounting
Nut M10 x 0.75 and serrated washer 3/8”
Specifications Protection Class Din 40050
IP 65
Specifications Recommended Operating Wiper Current
= 1 µA
Specifications Repeatability
0.02 (=3.46º) %
Specifications Resistance Element
Conductive Plastic
Specifications Resistance Tolerance
20 %
Specifications Shaft
Brass | Nickel plated
Specifications Shock Iec 68000 2 27
30 g | 7 ms
Specifications Size
Housing profile 13 x 13 mm
Specifications Special Features
Very small dimensions | 6 - 100 revolutions | Up to 15 x 106 movements | Excellent linearity | High resolution – better than 0.1%
Specifications Static Permitted Shaft Loading Axial And Radial
1 N
Specifications Temperature Range
-25 to 75 º C
Specifications Torque
= 1 N·cm
Specifications Effective Temperature Coefficient Of The
5 ppm/K
Specifications Vibration
30 to 2000 Hz | Amax = 0.75 mm | amax = 10
Specifications Weight
37 g
Specifications Wiper Assembly
Precious Metal multi-finger wiper
