Ultra-Met Grade Designations - Tungsten Carbide Inserts

Name: Ultra-Met Grade Designations - Tungsten Carbide Inserts
Brand: Ultra-Met
SKU: STA-26b047
Price: 29.99 USD
Availability: OutOfStock

SKU:STA-26b047

Optimize your machining with Ultra-Met Grade Tungsten Carbide Inserts. Superior hardness, durability, and precision for various materials.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Upgrade your machining operations with Ultra-Met Grade Tungsten Carbide Inserts. These inserts feature a nominal composition of 94% Tungsten Carbide and 6% Cobalt, ensuring exceptional hardness (93.5 HRA) and durability. With an ANSI Code of C2/C3 and ISO Code of K10, these inserts are perfect for general purpose and light finishing applications on materials like cast iron, non-ferrous metals, and non-metallic materials. The ultra-fine grain size enhances precision and performance, while the Transverse Rupture Strength of 400 ksi guarantees reliability under pressure. Trust in the quality and longevity of these inserts for your machining needs.

Product Specifications

Classifications Ansi Code

C2/C3

Classifications Applications

General Purpose and Light Finishing (Machining - Cast Iron, Non-Ferrous, and Non-Metalic Materials)

Classifications Grades

Tungsten Carbide

Classifications Grain Size

Ultra Fine

Classifications Iso Code

K10

Nominal Composition Cobalt Co

6.00%

Nominal Composition Tungsten Carbide Wc

94.00%

Physical Properties Density

14.82 g/cc

Physical Properties Hardness Hra

93.5 Ra

Physical Properties Transverse Rupture Trs

400 ksi | 400000 psi

Ultra-Met Grade Designations - Tungsten Carbide Inserts
