Ultra-Met Grade Tungsten Carbide Inserts
Ultra-Met Grade Tungsten Carbide Inserts
SKU:STA-bc68a4
Premium Ultra-Met Grade Tungsten Carbide Inserts for precise roughing cuts. Exceptional hardness and durability.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Ultra-Met Grade Tungsten Carbide Inserts
$39.99
Quantity: 1
Claim Your Seller Account
Ultra-Met Grade Tungsten Carbide Inserts
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your machining capabilities with our Ultra-Met Grade Tungsten Carbide Inserts. Crafted with a high-quality blend of 69.00% Tungsten Carbide, 14.50% Tantalum Carbide, and other premium materials, these inserts offer exceptional hardness at 91.3 HRA and a fine/medium grain size for precise roughing cuts on steels. With an ANSI Code of C5 and ISO Code of P35/M25, they ensure reliable performance in demanding applications. Trust in the durability and efficiency of these inserts for superior machining results.
Product Specifications
Classifications Ansi Code
C5
Classifications Applications
Roughing Cuts (Machining - Steels)
Classifications Grades
Tungsten Carbide
Classifications Grain Size
Fine/Medium
Classifications Iso Code
P35/M25
Nominal Composition Cobalt Co
10.50%
Nominal Composition Niobium Carbide Nbc
14.50%
Nominal Composition Tantalum Carbide Ta
14.50%
Nominal Composition Titanium Carbide Tic
6.00%
Nominal Composition Tungsten Carbide Wc
69.00%
Physical Properties Density
12.38 g/cc
Physical Properties Hardness Hra
91.3 Ra
Physical Properties Transverse Rupture Trs
350 ksi | 350000 psi
