Ultra-Met Tungsten Carbide Grades
Ultra-Met Tungsten Carbide Grades
SKU:STA-9c91b8
High-performance Ultra-Met Tungsten Carbide Grades for roughing cuts on various materials. Superior hardness, density, and strength.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Ultra-Met Tungsten Carbide Grades
$99.99
Quantity: 1
Claim Your Seller Account
Ultra-Met Tungsten Carbide Grades
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ultra-Met Tungsten Carbide Grades offer high-performance cutting capabilities ideal for roughing cuts on cast iron, non-ferrous, and non-metallic materials. With a fine to medium grain size, these grades deliver superior hardness (90.2 HRA), high density (14.07 g/cc), and excellent transverse rupture strength (540 ksi). Composed of 85% Tungsten Carbide along with Cobalt, Titanium Carbide, Tantalum Carbide, and Niobium Carbide, these grades ensure durability and precision in machining applications.
Product Specifications
Classifications Ansi Code
C1
Classifications Applications
Roughing Cuts (Machining - Cast Iron, Non-Ferrous, and Non-Metalic Materials)
Classifications Grades
Tungsten Carbide
Classifications Grain Size
Fine/Medium
Classifications Iso Code
K40
Nominal Composition Cobalt Co
12.00%
Nominal Composition Niobium Carbide Nbc
2.50%
Nominal Composition Tantalum Carbide Ta
2.50%
Nominal Composition Titanium Carbide Tic
0.50%
Nominal Composition Tungsten Carbide Wc
85.00%
Physical Properties Density
14.07 g/cc
Physical Properties Hardness Hra
90.2 Ra
Physical Properties Transverse Rupture Trs
540 ksi | 540000 psi
