Ultra-Met Tungsten Carbide Grades - C1/K25
Ultra-Met Tungsten Carbide Grades - C1/K25
SKU:STA-2871a0
High-performance Tungsten Carbide grades for precision machining applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Ultra-Met Tungsten Carbide Grades - C1/K25
$49.99
Quantity: 1
Claim Your Seller Account
Ultra-Met Tungsten Carbide Grades - C1/K25
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ultra-Met Grade Designations in Tungsten Carbide offer exceptional quality for roughing cuts in machining applications, specifically designed for cast iron, non-ferrous, and non-metallic materials. With a nominal composition of 92% Tungsten Carbide (WC) and 8% Cobalt (Co), these grades boast a hardness of 91.7 HRA, a density of 14.70 g/cc, and a Transverse Rupture Strength of 450 ksi. Precision-engineered with an Extra Fine grain size, these grades ensure superior performance and durability in demanding industrial environments.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classifications Ansi Code
C1
Classifications Applications
Roughing Cuts (Machining - Cast Iron, Non-Ferrous, and Non-Metalic Materials)
Classifications Grades
Tungsten Carbide
Classifications Grain Size
Extra Fine
Classifications Iso Code
K25
Nominal Composition Cobalt Co
8.00%
Nominal Composition Tungsten Carbide Wc
92.00%
Physical Properties Density
14.70 g/cc
Physical Properties Hardness Hra
91.7 Ra
Physical Properties Transverse Rupture Trs
450 ksi | 450000 psi
