Ultra-Met Tungsten Carbide Grades - C1/K25
Ultra-Met Tungsten Carbide Grades - C1/K25
SKU:STA-2871a0
High-performance Tungsten Carbide grades for precision machining applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Ultra-Met Tungsten Carbide Grades - C1/K25
$49.99
Quantity: 1
Claim Your Seller Account
Ultra-Met Tungsten Carbide Grades - C1/K25
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ultra-Met Grade Designations in Tungsten Carbide offer exceptional quality for roughing cuts in machining applications, specifically designed for cast iron, non-ferrous, and non-metallic materials. With a nominal composition of 92% Tungsten Carbide (WC) and 8% Cobalt (Co), these grades boast a hardness of 91.7 HRA, a density of 14.70 g/cc, and a Transverse Rupture Strength of 450 ksi. Precision-engineered with an Extra Fine grain size, these grades ensure superior performance and durability in demanding industrial environments.
Product Specifications
Classifications Ansi Code
C1
Classifications Applications
Roughing Cuts (Machining - Cast Iron, Non-Ferrous, and Non-Metalic Materials)
Classifications Grades
Tungsten Carbide
Classifications Grain Size
Extra Fine
Classifications Iso Code
K25
Nominal Composition Cobalt Co
8.00%
Nominal Composition Tungsten Carbide Wc
92.00%
Physical Properties Density
14.70 g/cc
Physical Properties Hardness Hra
91.7 Ra
Physical Properties Transverse Rupture Trs
450 ksi | 450000 psi
