Upgrade your motorsports experience with the SP2846350082101 Shaft-Type Rotary Sensor from Novotechnik. This sensor boasts a highly robust potentiometer designed for demanding industrial and mobile applications, ensuring excellent lifetime durability exceeding 50 million movements. With features like single or electrically redundant channels, wide temperature range, and precise mechanical adjustment, this sensor offers exceptional performance at a competitive price. The stainless steel shaft, conductive plastic resistance element, and precious metal wiper assembly guarantee reliable and accurate measurements. Easily mountable with superior IP67 sealing, this sensor is built for reliability under extreme conditions.
Product Specifications
Specifications Cable Length
1,000 mm
Specifications Cable Type
Raychem 55, 22 AWG
Specifications Continuous Mechanical Angles
360 º
Specifications Coupling Type
Push-on Coupling
Specifications Defined Electrical Angle
08 º | 100 º | 345 º
Specifications Defined Electrical Angle Tolerance
2
Specifications Dielectric Strength 50 Hz 2 S 1 Bar 500 Vac
= 100 µA
Specifications Electrical Angle
350
Specifications Electrical Connections Standard
1 = red, 2 = white, 3 = black | 1-channel: 3 conductors | Diameter = 2.1 mm | l=1000 mm | Raychem 55
Specifications Housing And Bearing
High-grade | Temperature-resistant plastic
Specifications Housing Material
Duraplast
Specifications Insulation Resistance 500 Vdc 1 Bar 2 S
= 10 MO
Specifications Life
> 50x106 Movements
Specifications Linearity
0.3 %
Specifications Maximum Allowed Wiper Current In Case Of Malfunct
10 mA
Specifications Maximum Dynamic Shaft Loading Axial And Radial
20 N
Specifications Maximum Operational Speed
120 rpm
Specifications Maximum Permissible Applied Voltage
42 V
Specifications Maximum Static Shaft Loading Axial And Radial
20 N
Specifications Maximum Torque For Mounting Screws With Washer
180 N·cm
Specifications Mounting
2 fillister head screws M4 with washers
Specifications Mounting Position
Any Orientation
Specifications Nominal Resistance
3 kO | 5 kO
Specifications Protection Class
IP67
Specifications Recommended Operating Wiper Current
= 1 µA
Specifications Repeatability
0.01 %
Specifications Resistance Element
Conductive Plastic
Specifications Resistance Tolerance
20 %
Specifications Shaft
Stainless Steel
Specifications Special Features
Highly robust potentiometer for demanding industrial and mobile applications | Excellent lifetime - in excess of 50 million movements | Single channel or fully electrically redundant | Easy mounting and mechanical adjustment | Excellent price/performance ratio | Plastic or aluminum housing | Wide temperature range | Elastomer damped wipers | Sealed to IP 67 | Two shaft styles, including easy “push-on” coupling
Specifications Temperature Range
-40 to 150 º C
Specifications Effective Temperature Coefficient Of The
5 ppm/K
Specifications Vibration
5 to 2000 Hz | Amax = 0.75 mm | amax = 20 g
Specifications Weight
30 g
Specifications Wiper Assembly
Precious Metal multi-finger wiper
