UM10 Grade 14mm Diameter 3-Hole 30° Precision Ground Carbide Rod

Name: UM10 Grade 14mm Diameter 3-Hole 30° Precision Ground Carbide Rod
Brand: Ultra-Met
SKU: SOL-b0462b
Price: 89.99 USD
Availability: OutOfStock

SKU:SOL-b0462b

Premium UM10 Grade 14mm 3-Hole Carbide Rod for precision machining with ISO h6 tolerance. Ideal for industrial use.

$89.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The UM10 Grade 14mm Diameter Three-Hole 30 Degree Precision Ground Carbide Rod is a top-tier solid carbide rod ideal for precision machining applications. With a polished finish and international standard ISO h6 tolerance, this carbide rod ensures consistent performance. The 1.40mm hole diameter with tight tolerances, 330mm length (+5mm | 0mm), and 7.05mm Between Centers diameter make it a reliable choice for industrial needs.

Product Specifications

Classifications Between Centers Bc Diameter

7.05 mm

Classifications Between Centers Bc Diameter Tolerance

Â±0.40 mm

Classifications Brands

Ultra-MetÂ®

Classifications Carbide Grade

UM10

Classifications Diameter

14 mm

Classifications Finish

Polished

Classifications Hole D

1.40 mm

Classifications Hole D Tolerance

0.20 mm

Classifications International Organization For Standardization I

Classifications Length

330 mm

Classifications Length Tolerance

+5 mm | 0 mm

Classifications Material

Carbide

Classifications Note

All inventory subject to prior sales.

Classifications Pitch

76.18 mm

Classifications Shipping Weight

0.878357475 Kilogram
