UNC/UNF Two-Piece Split Shaft Collar with Threaded Hub

Name: UNC/UNF Two-Piece Split Shaft Collar with Threaded Hub
Brand: Stafford Manufacturing Corp.
SKU: ROU-a0cf89
Price: 24.99 USD
Availability: OutOfStock

SKU:ROU-a0cf89

Precision-engineered two-piece split collar with threaded hub for superior clamping on UNF shafts. Secure, easy to adjust, and RoHS2 & REACH compliant.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The UNC/UNF Two-Piece Split Shaft Collar with Threaded Hub is a precision-engineered solution designed for bearing inner-race applications on standard UNF shafts. Featuring a precision-machined hub on the face that minimizes contact area, reducing friction significantly. This collar offers superior holding power compared to set-screw types, ensuring secure placement anywhere on the shaft. Non-marring, easily adjustable, and with high clamping power, this Steel collar is RoHS2 and REACH compliant, ideal for various industrial applications.

Product Specifications

Dimensional Attributes Outside Diameter

2.375 in

Dimensional Attributes Recessed Screw

Dimensional Attributes Screw Material

Alloy Steel

Dimensional Attributes Screw Size

1/4-28 x 5/8

Dimensional Attributes Threaded Bore Size

1-1/2-12

Dimensional Attributes Width

0.562 in

Specifications Alloy

1215

Specifications Approximate Weight

0.43 lb

Specifications Country Of Origin

USA

Specifications Finish

Black Oxide

Specifications Material

Steel

Specifications Part Number

HUB8L108F

Specifications Reach Compliant

Yes

Specifications Rohs2 Compliant

Yes

Specifications Series

Solution

Specifications Type

Low Profile

Specifications Upc Code

662786030260
