UNEF-2B 1/4-32 Rotary Switch Boot

Name: UNEF-2B 1/4-32 Rotary Switch Boot
Brand: ZAGO Manufacturing
SKU: SWI-46efb8
Price: 24.99 USD
Availability: OutOfStock

SKU:SWI-46efb8

Premium silicone rotary switch boot for durable switch protection against harsh elements. IP68 rated, resistant to extreme temps & corrosive substances.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The UNEF-2B 1/4-32 Rotary Switch Boot is a top-quality, silicone-made protective sleeve designed to shield standard switches effectively. With an IP68 rating, it resists harsh elements like water, oil, dust, and more. This boot ensures durability with resistance to fungus, acids, and extreme temperatures from -93 to +400 °F. Ideal for aerospace, industrial, marine, medical, and military applications, providing reliable protection in diverse environments.

Product Specifications

Specifications Applications

Specifications Base Width Hex

0.375 in

Specifications Boot Height

0.23 in

Specifications Bushing Thread Size Unified

1/4-32 UNEF-2B

Specifications Color

Black | Gray

Specifications Durometer

Specifications Enclosure Protection

IP68 (Under Normal Conditions)

Specifications External Pressure Range

15 psi

Specifications Internal Pressure Range

15 psi

Specifications Material

Silicone

Specifications Mounting Nut

Corrosion Resistant - Nickel Plated Brass

Specifications Note

Designed to protect from water, oil, sand, dust, dirt, humidity, precipitation and other contaminants.

Specifications Resistant To

Specifications Temperature Range

-93 to +400 ÂºF

Specifications Thread Type

Unified National Coarse Thread (UNC)

UNEF-2B 1/4-32 Rotary Switch Boot
