Unified/Straight Thread Sealing Plug with Neoprene O-Ring

Name: Unified/Straight Thread Sealing Plug with Neoprene O-Ring
Brand: MOCAP LLC
SKU: SEA-f8f565
Price: 129.99 USD
Availability: OutOfStock

SKU:SEA-f8f565

Protect threaded ports with precision! Unified/Straight Thread Sealing Plug for airtight security.

$129.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Unified/Straight Thread Sealing Plug with Neoprene O-Ring by MOCAP is engineered to safeguard threaded ports from moisture, dust, and damage, ensuring superior protection during production, shipping, and storage. Featuring a sealing lip and five complete threads, this plug guarantees a secure seal. Crafted from polypropylene with a Neoprene Rubber O-Ring, it offers a perfect fit for thread sizes ranging from 7/16-20 to 1-5/8-12. Easily applied and removed by hand or tools, this plug is ideal for diverse applications requiring airtight sealing.

Product Specifications

Features 0

Our SPU Series Plugs are: Molded in red polypropylene (Standard applications)Sized to fit Unified/Straight Threads from 7/16-20 to 1-5/8-12Neoprene Rubber O-Ring

Manufacturing Notes 0

MOCAP stocks sealing plugs for Unified/Straight Threads in both red polypropylene and yellow nylon materials in many sizes for immediate shipment.Micro-Packs are only available online.These Sealing Plugs are also available with a factory-fit Neoprene Rubber O-Ring when a perfect seal is required.

Specifications Box Quantity

1000

Specifications Color

Red

Specifications Flange Outer Diameter Dimension A

1.650 in | 41.9 mm

Specifications Length Dimension C

0.590 in | 15.0 mm

Specifications Material

Polypropylene

Specifications Micro Pack Quantity

Specifications Mini Pack Quantity

200

Specifications O Ring Material

Neoprene Rubber

Specifications Standards

RoHS Compliant

Specifications Stem Height Dimension B

0.590 in | 15.0 mm

Specifications To Fit Standard Thread Size

1 5/16-12

Unified/Straight Thread Sealing Plug with Neoprene O-Ring
