Unilok 316 SS Female Connector - 3/8 Tube Fitting x 1/4-18 FNPT

Unilok 316 SS Female Connector - 3/8 Tube Fitting x 1/4-18 FNPT

HEM-9be534

Premium Unilok 316 SS Female Connector for precise instrumentation fittings. Durable, leak-free, and corrosion-resistant. Ideal for 3/8in Tube x 1/4-18 FNPT.

$17.05
$17.05
Sale

Initiate Order

Unilok 316 SS Female Connector - 3/8 Tube Fitting x 1/4-18 FNPT

Unilok 316 SS Female Connector - 3/8 Tube Fitting x 1/4-18 FNPT

$17.05

Quantity: 1

Claim Your Seller Account

Unilok 316 SS Female Connector - 3/8 Tube Fitting x 1/4-18 FNPT

Unilok 316 SS Female Connector - 3/8 Tube Fitting x 1/4-18 FNPT

$17.05

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Unilok 316 SS Female Connector is a premium choice for secure and leak-free connections. With a 3/8-inch Tube Fitting and 1/4-18 FNPT, it ensures reliable performance in instrumentation applications. Crafted from high-quality 316 SS, this straight connector offers durability and corrosion resistance. The precise dimensions and TF x FNPT end connections guarantee a perfect fit. Trust Unilok for precision engineering and superior quality.

Product Specifications

Attributesoptions Attributesoptions
Meet or exceed the MIL-STD-188-125-1 requirementsInductive InputChoice of Termination ConfigurationsQuick Disconnect Terminal TabsThreaded StudsConnectorsCan be supplied with HEMP Protection ModulesSupplied with Certified PCI data upon requestExisting Designs for:Other Power Lines (Intersite)Audio/Data Lines (Intersite)Control/Signal Lines (Intersite)Existing Applications include:AC/DC powerTelephone LinesAnalog Fire AlarmsServo MotorsSynchro TransmitterCustom tailoring for your unique application
Electrical Ratings Current
5 A
Electrical Ratings Dcr
≤ 0.5 Ω
Electrical Ratings Dwv Dc
600 V
Electrical Ratings Frequency
DC to 60 Hertz
Electrical Ratings Mil Std 220 Insertion Loss Limit
100 dB Minimum from 14 kHz through 10 GHz
Electrical Ratings Voltage Peak
177
Electrical Ratings Voltage Vrms
125
Pci Hemp Parameters Common Mode Peak Short Circuit Current
2500 A
Pci Hemp Parameters Common Mode Residual Peak Current
≤ 1.0 A
Pci Hemp Parameters Common Mode Source Impedance
≥ 60 Ω
Pci Hemp Parameters Type
Short Pulse
Pci Hemp Parameters Type Of Injection
Common Mode | Wire-to-ground
Pci Hemp Parameters Wire To Ground Load Impedance
2 Ω
Pci Hemp Parameters Wire To Ground Peak Short Circuit Current
2500 A
Pci Hemp Parameters Wire To Ground Residual Peak Current
≤ 1.0 A
Pci Hemp Parameters Wire To Ground Source Impedance
≥ 60 Ω
Specifications Corrosion
Hermetically sealed steel or aluminum enclosures with tin-lead plating
Specifications Fungus
Non-nutritive materials are used
Specifications Humidity
10 to 90 %
Specifications Maximum Altitude
15000 ft
Specifications Note
Full load from 100 KHz to 20 MHz.When tested with external V130LA20B MOV connected from each line to ground.
Specifications Operating Temperature
-40 to +71 ºC
Specifications Storage Temperature
-55 to +105 ºC
Specifications Voltage
0 to 480 V
