V200P Pneumatic Positioner with 4-20 mA Feedback Module

Name: V200P Pneumatic Positioner with 4-20 mA Feedback Module
Brand: Caylor Industrial Sales, Inc.
SKU: ACT-cf731a
Price: 249.99 USD
Availability: OutOfStock

SKU:ACT-cf731a

Enhance valve control with the V200P Pneumatic Positioner featuring precise feedback module, optimal performance, and robust design.

$249.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The V200P Pneumatic Positioner with 4-20 mA feedback module is a high-performance solution for precise valve control in pneumatic applications. With a supply pressure of under 145 psi, linearity error under 0.7% f.s, and hysteresis under 0.4% f.s, this positioner ensures accurate and reliable operation. It offers a wide temperature range from -40 to +185 ºF, NEMA 4X and IP66 protection against ingress and corrosion, and complies with industry standards for robustness and durability. Ideal for use in diverse industrial settings, this positioner guarantees exceptional performance and longevity.

Product Specifications

Specifications Air Connections

1/4" NPT

Specifications Air Consumption At 87 Psi

0.35 scfm

Specifications Cable Entry

1/2" NPT

Specifications Gauges

1/8" NPT

Specifications Hysteresis

<0.4% f.s

Specifications Ingress Corrosion Protection

NEMA 4X and IP66

Specifications Linearity Error

<0.7% f.s

Specifications Output Flow Capacity At 87 Psi

28.3 scfm

Specifications Repeatability

<0.3% f.s

Specifications Standard Coating

Polyester

Specifications Supply Pressure

<145 psi | <1 MPa

Specifications Temperature Range

-40 to +185 ÂºF | -40 to +85 ÂºC

Specifications Weight

3.2 lbs | 1.45 kg

Specifications Weight With Gauges

3.4 lbs | 1.54 kg
