V6 Standard 70" Industrial Printing System
V6 Standard 70" Industrial Printing System
SKU:V6S-c51a97
Revolutionize industrial printing with the V6 Standard 70" Digital Printing System - precision, speed, and customization in one!
Regular price
$18,500.00
Regular price
Sale price
$18,500.00
Unit price
per
Initiate Order
V6 Standard 70" Industrial Printing System
$18,500.00
Quantity: 1
Claim Your Seller Account
V6 Standard 70" Industrial Printing System
$18,500.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The V6 Standard 70 Inch Industrial Digital Printing System is a cutting-edge modular solution designed for Industry 4.0 environments. With a high resolution of 180 dpi and a printing speed of up to 60 m/min, this system offers unparalleled efficiency and customization capabilities. Its Color Printing System supports 2 Colors DUO, while the integrated message editor allows for the printing of variable fields. Ideal for institutions and government buyers seeking advanced printing technology for their operations.
Product Specifications
Additional Information Additional Information
Printing immediately sets Useful, long life span with low maintenance Energy efficientSeveral heights availableInstant on/offSafety through double activation inputAdjustable intensity
Advantages Advantages
Customization. Short print runs. PromotionsReduction of stock of pre-printed containersPractically zero maintenanceNo stoppages to change consumablesPrinting on ramps of any inclination
Characteristics Characteristics
Opposite facesDifferent heightsDifferent lines (independent)Multiple densities and contrastsHigh quality bar codes. GS-1 standardIntuitive user environmentActual on-screen preview of the message to be printed (WYSIWYG)Oil based and UV LED inksExternal hardware message selectionIntegration with post-print bar code readerScripting for full customization of jobs
Electrics Alternating Current Ac Voltage
88 to 132 V | 176 to 264 V
Electrics Communication Ports
1 x RS-232 | 1 x RS-422/485/232 (Optional) | 1 x USB | 1 x WiFi (Optional) | 2 x Ethernet 1GB
Electrics Frequency
47 to 63 Hz
Electrics Input Per Block
1 x Encoder | 1 x Printing Signal
Electrics Maximum Power
1200 W
Electrics Output Per Block
2 x Programmable | 2 x Status Indicators
Environmental Console Ingress Protection Ip
Ingress Protection (IP52)
Environmental Work Environment
5 to 45 ºC | 41 to 113 ºF
Orientation Option Orientation Options
Downjet | Lateral | Upjet
Print Bar Codes
EAN/UPC | GS1 Datamatrix | GS1 QR Code | GS-1 Standard | GS1-128 | ITF-14
Print Character Coding
Unicode
Print Color Printing System
2 Colors DUO
Print Densities
3 Levels
Print Font Type
Open Type⢠| TrueTypeâ¢
Print Height
70/70 mm
Print Maximum Length
+100 m
Print Printing Of Variable Fields
Of user (Customized fields) and Automatic Fields (Expiry Dates, Shift Codes, Counters)
Print Print Head Resolution
180 dpi
Print Print Speed At 180 Dots Per Inch Dpi
60 m/min
Print Speed Depending On Resolution
0.2 to 192 m/min
Technical Specs Communications
Own communications protocolWindows⢠DriverConnectivity with external database and ERP Remote assistance
Technical Specs Oil Based And Ultraviolet Uv Light Emitting Diod
Black | Black (High Contrast) | Cyan | Magenta | Others (Consult) | Yellow
Technical Specs Options
Alarm Beacons | Bar Code Reader for Selecting Products | Encoder | External Message Selection | Post-Printing Bar Code Verification
Technical Specs Printable Products
Coated Cardboard | EPS | Foam | Glossy | Metal | Paper | Plastic | Porous | Textiles | Wood
Technical Specs User Interface
15" color touchscreenSelection of preview messagesWYSIWYGDiagnosticsIntegrated message editor
