VBW Series 1-1/4 Inch (in) Size Female Full Port 2-Way Metal Ball Valve

Name: VBW Series 1-1/4 Inch (in) Size Female Full Port 2-Way Metal Ball Valve
Brand: Pneuline Supply, Inc.
SKU: VBW-f22d40
Price: 49.99 USD
Availability: OutOfStock

SKU:VBW-f22d40

N/A

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

This two-way brass ball valve has a pressure rating of 600 psi, and 150 psi is the working steam pressure. The maximum temperature is 366 ºF. The stem is blow-out proof, the ball is Chrome-plated Brass and the seat is PTFE. There is an adjustable screw packing nut. Both ports are equal in size and female NPT threads.

Product Specifications

Note

If you do not see exactly what you are looking for, please contact our sales department.Also available in 316 Stainless Steel. It has an internal entry blow-out-proof stem. The pressure rating is 2000 psi with a pressure test of API 598 psi. The ball seat and body seal are PTFE. Both ports are equal in size and female NPT threads.

Technical Specs Material

Chrome Plated Brass

Technical Specs Maximum Operating Temperature

366 ºF

Technical Specs Operating Pressure

150 psi | 600 psi

Technical Specs Port Connection Type

Female

Technical Specs Port Size

1-1/4 in

Technical Specs Port Type

Full Port

Technical Specs Series

VBW

VBW Series 1-1/4 Inch (in) Size Female Full Port 2-Way Metal Ball Valve
