Vecoplan® VTH Series 140 st/hr Horizontal Drum Chipper
Vecoplan® VTH Series 140 st/hr Horizontal Drum Chipper
SKU:HOR-9fe372
High-capacity Vecoplan® drum chipper for precise and efficient wood chip production in chipboard, paper, and biomass plants.
Regular price
$99,999.99
Regular price
Sale price
$99,999.99
Unit price
per
Initiate Order
Vecoplan® VTH Series 140 st/hr Horizontal Drum Chipper
$99,999.99
Quantity: 1
Claim Your Seller Account
Vecoplan® VTH Series 140 st/hr Horizontal Drum Chipper
$99,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Vecoplan® VTH Series 140 st/hr Horizontal Drum Chipper is a powerhouse designed for the chipboard and paper industry, as well as biomass power plants. With its 49in x 14in infeed opening, 51in rotor diameter, and 140 st/hr capacity, it delivers high-quality wood chips. Featuring 2 to 4 knives and a 335 to 600 hp motor, this chipper ensures precision and efficiency. The Vecoplan® VTH Series' durability, low maintenance, and performance make it a cost-effective solution for wood chip production, contributing to revenue generation in various industries.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information 0
Many of the VTH-Series™ Drum Chippers are available with optional cutting rotor designs. If a larger and rougher particle size is acceptable, many of the VTH-Series™ models are available with the patented TorsionPoint™ “U”-Rotor™. Vecoplan® has used this rotor in its vertical shredders since 1983 and is the preferred shredding method used in industry today. The standard cutting rotor design is a precision granulator or drum chipper rotor in 2 to 4-knife configurations in a moderately open design. The knife rotor turns at moderate RPM and utilizes sharp knives similar to conventional granulator or chipper blades. A unique clamping system secures the knives in place and affords many sharpening intervals. When a small and uniform granulate or chip is needed, the knife rotor is suggested. In the wood industry, Vecoplan® has been producing high quality drum chippers since 1969.While durability and extremely low maintenance are highly valuable benefits of the VTH-Series™, they pale in comparison to the performance it delivers. The unique design and resulting efficiencies contribute to both a lower purchase price and lower subsequent operating costs.While often used in wood recycling, referring to the Vecoplan® VTH Series Drum Chipper as just a “wood recycle machine” is a misnomer, in that a powerful drum chipper is equal to other machines in a plant’s production system. Used directly in the production line in sawmills for evacuation and wood waste recycling, the Vecoplan® VTH Series Drum Chippers produce high quality chips for the production of chipboard, paper, wood pulp, and fuel. In short - a large capacity wood chipper produces revenue.
Manufacturing Notes 0
Chipping Length, Maximum Capacity: Depending on input material and chipping length.
Specifications Approximate Rotor Speed
425 rpm
Specifications Chipping Length
1 in
Specifications Infeed Opening Length
49 in
Specifications Infeed Opening Width
14 in
Specifications Maximum Capacity
140 st/h
Specifications Number Of Infeed Rollers
9
Specifications Number Of Tools
2 to 4
Specifications Required Motor Power
335 to 600 hp
Specifications Rotor Diameter
51 in
Specifications Weight
50,700 lb
