Vecoplan VTH 15-VU Series Horizontal Waste Shredder
Vecoplan VTH 15-VU Series Horizontal Waste Shredder
SKU:HOR-25a780
Vecoplan VTH 15-VU Series 16 st/hr Horizontal Waste Shredder - High-performance shredding for industrial needs.
Regular price
$25,999.00
Regular price
Sale price
$25,999.00
Unit price
per
Initiate Order
Vecoplan VTH 15-VU Series Horizontal Waste Shredder
$25,999.00
Quantity: 1
Claim Your Seller Account
Vecoplan VTH 15-VU Series Horizontal Waste Shredder
$25,999.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Vecoplan VTH 15-VU Series 16 st/hr Maximum Capacity Horizontal Waste Shredder is a high-performance mid-sized machine designed to efficiently shred various materials like plastic, wood strips, mouldings, and lumber with its 4-Way, Indexable Cutting Inserts and High Output “Torsion Point” Cutting Rotor. Equipped with features such as Easy Accessibility, Heavy Spherical Roller Bearings, and a Lifetime Limited Warranty on the Cutting Rotor, this shredder ensures durability and ease of maintenance. Manufactured under ISO 9001 standards, this shredder offers a low to medium speed/high torque design, making it ideal for industrial applications.
Product Specifications
Additional Information 0
The VTH-VU Series™ Horizontal Shredders are available with optional cutting rotor designs. These shredder models are also available with a precision granulator or drum chipper rotor in 2 to 4-knife configurations in a moderately open design. The knife rotor turns at moderate RPM and utilizes sharp knives similar to conventional granulator or chipper blades. A unique clamping system secures the knives in place and affords many sharpening intervals. When a small and uniform granulate or chip is needed, the knife rotor is suggested. If a larger and rougher particle size is acceptable, the VTH-VU Series™ models are supplied with the patented TorsionPoint™ “U”-Rotor™. Vecoplan® has used this rotor in its vertical shredders since 1983 and is the preferred shredding method used in industry today. In the wood industry, Vecoplan® has been producing high quality drum chippers since 1969.While durability and extremely low maintenance are highly valuable benefits of the VTH-VU Series™, they pale in comparison to the performance it delivers. The unique design and resulting efficiencies contribute to both a lower purchase price and lower subsequent operating costs.The feed rate is determined by the amperage load that processing places on the cutting rotor, which in turn sends a signal to both the conveyor and the feed rollers for adjustment of the feed rate. Particle size, or chip size, is determined by changeable sizing screens similar to Vecoplan’s vertical shredders.
Specifications Approximate Rotor Speed
390 rpm
Specifications Approximate Weight
7,050 lb
Specifications Features
4-Way, Indexable Cutting Inserts | Easy Accessibility | Equity “Buyback” Guarantee | Heavy Spherical Roller Bearings | High Output “Torsion Point” Cutting Rotor | ISO 9001 Manufactured | Lifetime Limited Warranty on Cutting Rotor | Low to Medium Speed / High Torque Design | Oversized Drivetrain | Powerbelt Rotor Drive | Severe Duty Construction
Specifications Infeed Opening Length
21 in
Specifications Infeed Opening Width
6 in
Specifications Maximum Capacity
16 st/h
Specifications Number Of Infeed Rollers
2
Specifications Number Of Tools
30
Specifications Required Motor Power
50 to 100 hp
Specifications Rotor Diameter
20 in
Specifications Standards
International Organization for Standardization (ISO 9001)
Specifications Vibratory Conveyor Length
16 ft
