The Vecoplan VTH Series 180 st/hr Horizontal Drum Chipper is a powerhouse in the wood industry, designed for creating high-quality wood chips with maximum efficiency. Featuring a robust construction and precision granulator rotor design, it offers a chipping length of 1 inch and a maximum capacity of 180 st/hr. With Vecoplan's patented TorsionPoint™ “U”-Rotor™ and durable knife rotor configurations, this chipper ensures exceptional performance and low maintenance. Ideal for chipboard, paper, wood pulp, and fuel production, it integrates seamlessly into sawmills and biomass power plants for sustainable energy wood chip production.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information 0
Many of the VTH-Series™ Drum Chippers are available with optional cutting rotor designs. If a larger and rougher particle size is acceptable, many of the VTH-Series™ models are available with the patented TorsionPoint™ “U”-Rotor™. Vecoplan® has used this rotor in its vertical shredders since 1983 and is the preferred shredding method used in industry today. The standard cutting rotor design is a precision granulator or drum chipper rotor in 2 to 4-knife configurations in a moderately open design. The knife rotor turns at moderate RPM and utilizes sharp knives similar to conventional granulator or chipper blades. A unique clamping system secures the knives in place and affords many sharpening intervals. When a small and uniform granulate or chip is needed, the knife rotor is suggested. In the wood industry, Vecoplan® has been producing high quality drum chippers since 1969.While durability and extremely low maintenance are highly valuable benefits of the VTH-Series™, they pale in comparison to the performance it delivers. The unique design and resulting efficiencies contribute to both a lower purchase price and lower subsequent operating costs.While often used in wood recycling, referring to the Vecoplan® VTH Series Drum Chipper as just a “wood recycle machine” is a misnomer, in that a powerful drum chipper is equal to other machines in a plant’s production system. Used directly in the production line in sawmills for evacuation and wood waste recycling, the Vecoplan® VTH Series Drum Chippers produce high quality chips for the production of chipboard, paper, wood pulp, and fuel. In short - a large capacity wood chipper produces revenue.
Specifications Approximate Rotor Speed
350 rpm
Specifications Chipping Length
1 in
Specifications Infeed Opening Length
49 in
Specifications Infeed Opening Width
18 in
Specifications Maximum Capacity
180 st/h
Specifications Number Of Infeed Rollers
11
Specifications Number Of Tools
2 to 4
Specifications Required Motor Power
850 to 1350 hp
Specifications Rotor Diameter
63 in
Specifications Weight
68,350 lb
