Vectrax 38-1/2" Step Pulley Bench Drill Press
Vectrax 38-1/2" Step Pulley Bench Drill Press
SKU:DRI-d244b2
Precision drilling with 5 speeds, 1-1/2" cast iron capacity, and 1.5 hp motor
Regular price
$2,399.99
Regular price
Sale price
$2,399.99
Unit price
per
Initiate Order
Vectrax 38-1/2" Step Pulley Bench Drill Press
$2,399.99
Quantity: 1
Claim Your Seller Account
Vectrax 38-1/2" Step Pulley Bench Drill Press
$2,399.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Vectrax 38-1/2" Step Pulley Bench Drill Press is a versatile and reliable machine designed for precision drilling operations. With a drilling capacity of up to 1-1/2" in cast iron and 1-1/4" in steel, this drill press offers 5 spindle speeds ranging from 340 to 3000 rpm. The 3MT spindle taper, 1.5 hp motor, and radial head design ensure optimal performance. Ideal for heavy-duty metalworking tasks, this bench drill press is perfect for applications requiring accuracy and strength.
Product Specifications
Features Features
Bench drill presses, also known as bench top, are stationary presses that are mounted to a workbench. They are used for precision applications, on smaller workpieces and where limited space is a concern.Step pulleys are driven by a belt system that is manually changed to achieve a range of fixed speeds.Drill presses are used for several countersinking, counterboring, drilling, reaming and tapping operations. They are used for heavy-duty metalworking operations.
Technical Specs Base Length
21-5/8 in
Technical Specs Base Width
22 in
Technical Specs Brands
Vectrax
Technical Specs Column Diameter
4-1/2 in | 114.30 mm
Technical Specs Drilling Capacity Cast Iron
1-1/2 in
Technical Specs Drilling Capacity In Steel
31.75 mm | 1-1/4 in
Technical Specs Drill Head
Radial Head
Technical Specs Horsepower
1.5 hp
Technical Specs Machine Type
Drill Press
Technical Specs Manufacturer Part
RF-35
Technical Specs Maximum Spindle Speed
3000 rpm
Technical Specs Minimum Spindle Speed
340 rpm
Technical Specs Motor Phase
1 hp
Technical Specs Number Of Spindle Speeds
5 rpm
Technical Specs Radial Arm Length
38-1/2 in
Technical Specs Spindle Speed Control
Step Pulley
Technical Specs Spindle Taper
3MT
Technical Specs Spindle To Column Distance Decimal Inch
18.0000 in
Technical Specs Spindle Trave Length
5-1/16 in | 5.1181 in
Technical Specs Stand Type
Bench
Technical Specs Swing
38-1/2 in
Technical Specs Table Length
21 to 5/8 in | 550.00 mm
Technical Specs Table Widthdiameter
500 mm | 19.6850 in | 19-11/16 in
Technical Specs Voltage
220 V
