Versatile U-Fix Aluminum/Stainless Steel Dome Head Rivet
Versatile U-Fix Aluminum/Stainless Steel Dome Head Rivet
SKU:UFI-c3a188
Premium 4.8mm U-Fix Dome Head Rivet for versatile and secure fastening solutions. Ideal for automotive and trailer applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Versatile U-Fix Aluminum/Stainless Steel Dome Head Rivet
$29.99
Quantity: 1
Claim Your Seller Account
Versatile U-Fix Aluminum/Stainless Steel Dome Head Rivet
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 4.8mm Diameter and 24.8mm Body Length U-Fix Aluminum/Stainless Steel Dome Head Rivet is a premium fastening solution for a wide range of applications. Crafted with precision from Aluminum Alloy ALmg 2.5 and Stainless Steel AISI 430/434, this rivet combines durability and versatility. With a multi-grip feature, it securely fastens components like rails, frames, and cabin fixtures. Meet high-demand needs with a nominal shear force of 159 kgf and tensile force of 240 kgf. Ideal for automotive, interior, and trailer applications.
Product Specifications
Applications Automotive Application
InteriorThe U-Fix is a highly versatile purpose-built fastener, featuring an excellent multi-grip function ideal for a variety of purposes. Commonly used to secure components within the vehicle.
Nominal Dimensions Body Length
24.8 mm | 0.976 in
Nominal Dimensions Diameter
4.8 mm | 3/16 in
Nominal Dimensions Drillhole Size
5.0 mm | 0.197 in
Nominal Dimensions Head Diameter
9.8 mm | 0.386 in
Nominal Dimensions Head Thickness
1.45 mm | 0.057 in
Nominal Dimensions Mandrel Diameter
2.8 mm | 0.110 in
Nominal Dimensions Maximum Grip Range
19.8 mm | 0.780 in
Nominal Dimensions Minimum Grip Range
12.7 mm | 0.500 in
Nominal Forces Nominal Shear Force
159 kgf | 350 lbf
Nominal Forces Nominal Tensile Force
240 kgf | 528 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 2.5
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
3000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Stainless Steel AISI 430/434 or Equivalent
