Vinyl Round Cap 1.5"
Vinyl Round Cap 1.5"
SKU:ROU-bf430e
Versatile Vinyl Round Cap 1.5" for end protection and masking. Fits Metric Thread M4, various colors available, no additional tooling charge.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Vinyl Round Cap 1.5"
$29.99
Quantity: 1
Claim Your Seller Account
Vinyl Round Cap 1.5"
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Vinyl Round Cap 1.5" by MOCAP is a versatile and cost-effective solution for adding a polished finish and durable protection to consumer and industrial products. Designed to fit Metric Thread Size M4, this cap features an Inside Diameter of 0.137 in and a Wall Thickness of 0.033 in, ensuring a snug and secure fit. Not only can it be used as end caps, pipe caps, or tube caps for appearance finishing, but it also serves as a reliable masking cap for painting and coating processes under 300°F. Available in various colors and lengths, including 1.5", this dip molded cap requires no additional tooling charge, making it a convenient choice for all your product protection needs.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Features 0
MOCAP round vinyl plastic caps are available in sizes from 0.062 in to 6.00 in diameter.
Finishing And Appearance 0
MOCAP can dip mold round vinyl plastic caps in virtually any color to compliment your product as a finishing cap visible to end users. Consider MOCAP's other finishing and appearance Products.
Manufacturing Notes 0
Round Plastic Caps are stocked in many sizes, ready for immediate shipment or MOCAP can manufacture vinyl plastic caps to-order with the fastest lead-times in the industry.PMS or special color matching available if our standard color options do not meet your needs.Stocked Parts are in General Purpose 9500-002 Black Material, with some available in our General Purpose 9500-011 Red Material. See the size chart above for stock offerings.Box Quantities may vary on items which are available in multiple lengths. Use MOCAP vinyl plastic caps as durable and inexpensive caps to protect your product threads or surfaces during assembly or shipping. Review all of MOCAP's products.Micro-Packs are only available online.
Masking Applications 0
MOCAP vinyl plastic caps are often used as inexpensive and disposable single-use masking caps for painting and coating processes under 300 °F. For high temperature masking greater than 300 °F, consider MOCAP's High Temperature Vinyl or EPDM Masking Products good to 475 °F, or MOCAP Silicone Masking Products good to over 600 °F.
Specifications Box Quantity
5600
Specifications Inside Diameter Dimension A
0.137 in | 3.5 mm
Specifications Manufacturing Process
Dip Molded
Specifications Maximum Inside Length Dimension C
1.500 in | 38.1 mm
Specifications Micro Pack Quantity
112
Specifications Minimum Inside Length Dimension B
0.188 in | 4.8 mm
Specifications Mini Pack Quantity
1120
Specifications Stocked Length
0.5 in | 1 in | 1.5 in
Specifications To Fit Metric Thread Size
M4
Specifications Wall Thickness Dimension D
0.033 in | 0.8 mm
