Violet 3-Pin Wire Mount Plug Connector
Violet 3-Pin Wire Mount Plug Connector
SKU:PRO-c1271a
Enhance connectivity with our durable Violet 3-Pin Wire Mount Plug Connector. Designed for reliability and compliance with industry standards.
Regular price
$2.10
Regular price
Sale price
$2.10
Unit price
per
Initiate Order
Violet 3-Pin Wire Mount Plug Connector
$2.10
Quantity: 1
Claim Your Seller Account
Violet 3-Pin Wire Mount Plug Connector
$2.10
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your connectivity with our Violet 3-Pin Wire Mount Plug Connector. Designed for maximum durability, it features a C5210 gold-plated terminal, Polycarbonate/ABS body, and meets strict compliance standards. With a 0.05 to 0.08 mm² wire cross-sectional area and 1.0 to 1.2 mm cover diameter, this connector ensures reliable performance in various applications.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Violet
Specifications Connector Type
Wire Mount Plug
Specifications Cover Color
Violet
Specifications Cover Diameter
1.0 to 1.2 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.05 to 0.08 mm²
Specifications Number Of Pins
3
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.05 to 0.08 mm²
Specifications Wire Size
30-28 AWG
