Violet 3-Pin Wire Mount Socket Connector - 30-28 AWG
Violet 3-Pin Wire Mount Socket Connector - 30-28 AWG
SKU:PRO-1c7ecb
High-quality Violet 3-Pin Wire Mount Socket Connector for secure sensor connections, 30-28 AWG, ~250V AC/DC, 3.0A
Regular price
$2.10
Regular price
Sale price
$2.10
Unit price
per
Initiate Order
Violet 3-Pin Wire Mount Socket Connector - 30-28 AWG
$2.10
Quantity: 1
Claim Your Seller Account
Violet 3-Pin Wire Mount Socket Connector - 30-28 AWG
$2.10
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Violet 3-Pin Wire Mount Socket Connector is a high-quality solution for secure sensor connections. With a maximum AC/DC voltage of ~250V, this connector ensures reliable performance. It features a C5210 gold-plated terminal, Polycarbonate/ABS body, and Polycarbonate case for durability. Meeting standards like UL94-V0, this connector offers a maximum current rating of 3.0A. Designed for 30-28 AWG wires with a cross-sectional area of 0.05 to 0.08 mm², it guarantees secure and stable connections in diverse applications.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Violet
Specifications Connector Type
Wire Mount Socket
Specifications Cover Color
Violet
Specifications Cover Diameter
1.0 to 1.2 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.05 to 0.08 mm²
Specifications Number Of Pins
3
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.05 to 0.08 mm²
Specifications Wire Size
30-28 AWG
