High-performance VPM Toroidal Medical Transformer - 250 VA, Class F Insulation, CE, CRU®US Certified
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
VPM Series Toroidal Medical Transformer - 250 VA
$349.99
Quantity: 1
Claim Your Seller Account
VPM Series Toroidal Medical Transformer - 250 VA
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The VPM Series Toroidal Medical Transformer is a cutting-edge power solution designed for precision and reliability. With primary voltage options of 100, 120, 220, or 240 VAC at 50/60 Hz, and secondary dual voltage configurations for parallel or series connection, this transformer offers superior performance. It boasts Class F insulation, 4 KV dielectric isolation, low leakage current, and minimal stray fields. Ideal for medical applications, this transformer meets CE, CRU®US standards, ensuring top-notch safety and quality.
Product Specifications
Note Note
Custom designs available.RoHS Compliance: As of manufacturing date February 2016, all standard products meet the requirements of 2015/863/EU, known as the RoHS 3 initiative.Upon printing, this document is considered "uncontrolled".
Specifications Connection Type
Leads
Specifications Dielectric Isolation Primary To Secondary For 60
4 kV
Specifications Electrical Rating
250 V·A
Specifications Industry Standards
CE | CRU®US
Specifications Insulation Class
Class F, 155 ºC
Specifications Maximum Height
60 mm
Specifications Nominal Primary Voltage
100 V | 120 V | 220 V | 240 V
Specifications Nominal Secondary Voltage
12 V | 24 V
Specifications Outside Diameter
123 mm
Specifications Primary Frequency
50 Hz | 60 Hz
Specifications Safety
Medical
Specifications Secondary Connection Type
Parallel | Series
Specifications Secondary Power Volts X Ampva
250 V·A
Specifications Secondary Voltage In Parallel
12 V at 20.84 A
Specifications Secondary Voltage In Series
24 V CT at 10.42 A
Specifications Regulation
6.2 %
Specifications Temperature Rise
55 ºC
Specifications Weight
2.5 kg
