Waterproof Breakaway Connector
Waterproof Breakaway Connector
SKU:7AN-dd3b65
Rugged and waterproof 7-pin connector for commercial, military, and institutional use. Self-cleaning contacts, durable construction, and compatible with various cable diameters.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Waterproof Breakaway Connector
$29.99
Quantity: 1
Claim Your Seller Account
Waterproof Breakaway Connector
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Waterproof Breakaway Connector is a ruggedized solution for commercial, military, and institutional applications. With 7 conductors, gold-plated brass contacts, and black anodized aluminum shell, this connector ensures reliable performance in severe environments. Featuring waterproof capabilities up to 6 feet underwater, self-cleaning contacts, and compatibility with various cable diameters, it meets the demands of C4I Systems, Military Vehicles, and more. Designed for durability and performance, this connector is ideal for mission-critical installations.
Product Specifications
Applications 0
C4I Systems Military Vehicles Commercial Aircraft Telecommunications Equipment Missiles and Ordnance Medical Equipment Commercial / Industrial Equipment
Features 0
Plug and Jack breakaway connectors designed to function in severe environments Watertight in up to 6 feet of water Molded-in wiping-action contacts provide self-cleaning feature and eliminate issues with pin/socket open contacts Designed for multiple cable diameters Miniature versions are 50% smaller than standard connectors while maintaining many of the same performance characteristics
Options 0
7- or 10-pin (miniature version only) contacts Solder-type contacts or insulation-piercing contacts Wire strain relief or over-molded versions available for all plugs and jacks Panel mount versions are available for both front- and rear-mount panels Shielding is available in all connector choices All standard connector options also available in miniaturized versions
Specifications Application
Ruggedized Commercial / Military
Specifications Conductors
7
Specifications Contact Current Capacity
3 A
Specifications Contact Material
Gold-plated Brass
Specifications Contact Resistance
⤠150 mV
Specifications Contact Types
Solder
Specifications Disengagement Force
8 to 12 lb
Specifications Engagement Force
⤠14 lb
Specifications Insert Material
Thermoset Plastic
Specifications Mating
Axial Push-Pull Motion
Specifications Mating Cycles
5000
Specifications Plating Material
Black Anodize (standard) | Black Chrome (shielded)
Specifications Rear Accessory
Wire Strain Relief
Specifications Shell Material
Aluminum
Specifications Temperature
-55 to 85 ºC
