White Thermoplastic Polyester Round Rod
White Thermoplastic Polyester Round Rod
SKU:SHA-bb2f31
High-strength White Thermoplastic Polyester Round Rod for precision mechanical parts. Excellent wear resistance, low friction, and dimensional stability. ASTM compliant.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
White Thermoplastic Polyester Round Rod
$24.99
Quantity: 1
Claim Your Seller Account
White Thermoplastic Polyester Round Rod
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The White Thermoplastic Polyester Round Rod is an unreinforced, semi-crystalline thermoplastic polyester ideal for precision mechanical parts in high-load and wear conditions. With excellent wear resistance, low friction, and high strength, this rod offers exceptional dimensional stability and retains strength up to 180°F. It features good chemical and abrasion resistance, low moisture absorption, and can be machined with precision. Compliant with ASTM D4507 TPES211B55130.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications 0
Manifolds.Food equipment components.Pharmaceutical test equipment.Distribution valves.Bushings & Bearings.Wear Parts.
Characteristics 0
High strength & stiffness.Low friction.Good dimensional stability.Low moisture absorption.Excellent stain resistance.
Specifications Coefficient Of Friction Dry Vs Steel Dynamic Ptm
0.20
Specifications Coefficient Of Linear Thermal Expansion At 73f 14
30.30 x 10-5 in/in/ºF
Specifications Compressive Modulus 73f
420000 psi
Specifications Compressive Strength At 10 Deformation 73f
15000 psi
Specifications Dielectric Strength Short Time Astm D149
385 V/m
Specifications Flammability At 118 Ul94
HB
Specifications Flexural Strength
18000 psi
Specifications Hardness Durometer Shore D Scale 73f Astm D2240
87D
Specifications Hardness Rockwell Astm D785
M93/R125
Specifications Heat Deflection Temperature At 264 Psi
240 ºF
Specifications Impact Strength Notched At 73f Astm D256
0.50 ft·lb/in
Specifications Max Continuous Service Temperature In Air
210 ºF
Specifications Specific Gravity Astm D792
10.41
Specifications Standard Length
10 ft | 8 ft
Specifications Tensile Modulus Astm D638
460000 psi
Specifications Tensile Strength Astm D638
12400 psi
Specifications Tolerance
+ 0.002 in | - 0.00 in
Specifications Volume Resistivity Astm D257
> 1013 ohm·cm
Specifications Water Absorption Saturation Astm D570
0.90 %
Specifications Weight
0.068 lb/ft
