The Wichita AquaMaKKs Water Cooled Clutches and Brakes with Composite Water Jacket are a pinnacle of pneumatic and hydraulic control technology. Featuring alternating friction discs and water jackets, these clutches and brakes ensure optimal torque transmission with axial force application from pneumatic, hydraulic, or spring set actuators. With copper wear plates for superior heat dissipation, they come in 19", 25", and 36" diameter sizes, offering torque ranges from 66,500 in.lb. @ 80 PSI up to 1,611,000 in.lbs. @ 100 PSI. Designed for durability and precision, these mechanisms excel in demanding industrial environments.
Product Specifications
Specifications Actuation
Air Applied
Specifications Assembly Number
7-236AM-W-1300
Specifications Bolt Circle Diameter C
1.060 in | 27 mm
Specifications Diameter A
45.51 in | 1156 mm
Specifications Diameter B
45.51 in | 1156 mm
Specifications Dynamic Torque Rating 100 Psi7 Bar
805000 lb·in | 90885 Nm
Specifications Dynamic Torque Rating 80 Psi55 Bar
644000 lb·in | 72708 Nm
Specifications Heat Capacity For Parallel Water Hosing
1750 hp | 1305 kW
Specifications Heat Capacity For Series Water Hosing
875 hp | 652 kW
Specifications Holes Quantity
10
Specifications Hole Circle
42 in | 1067 mm
Specifications Inner Diameter Length F
18.38 in | 467 mm
Specifications Length A
21.28 in | 541 mm
Specifications Length C
10 in | 254 mm
Specifications Length D
2.36 in | 60 mm
Specifications Length E
11.36 in | 289 mm
Specifications Manufacturer
Wichita Clutch
Specifications Maximum Bore Size
11.75 in | 298 mm
Specifications Outer Diameter Length F
44.50 in | 1130 mm
Specifications Pilot Diameter B
16.5 in | 419 mm
Specifications Plt Thickness
1.61 in | 41 mm
