Experience unrivaled performance with Wichita AquaMaKKs Water Cooled Clutches and Brakes featuring a composite water jacket. Designed for precision, these pneumatically or hydraulically controlled units offer exceptional heat dissipation with copper wear plates. Choose from 19", 25", and 36" diameter sizes with torque ranging from 66,500 to 1,611,000 in.lbs. @ 80 to 100 PSI. With dynamic torque ratings, high heat capacity, and durable construction, these clutches and brakes ensure reliable operation in demanding industrial settings.
Product Specifications
Specifications Actuation
Air Applied
Specifications Assembly Number
7-336AM-W-1300
Specifications Bolt Circle Diameter C
1.060 in | 27 mm
Specifications Diameter A
45.51 in | 1156 mm
Specifications Diameter B
45.51 in | 1156 mm
Specifications Dynamic Torque Rating 100 Psi7 Bar
1207500 lb·in | 136327 Nm
Specifications Dynamic Torque Rating 80 Psi55 Bar
996000 lb·in | 112448 Nm
Specifications Heat Capacity For Parallel Water Hosing
2550 hp | 1902 kW
Specifications Heat Capacity For Series Water Hosing
1275 hp | 951 kW
Specifications Holes Quantity
10
Specifications Hole Circle
42 in | 1067 mm
Specifications Inner Diameter Length F
18.38 in | 467 mm
Specifications Length A
26.76 in | 680 mm
Specifications Length C
17.05 in | 433 mm
Specifications Length D
2.36 in | 60 mm
Specifications Length E
15.36 in | 390 mm
Specifications Manufacturer
Wichita Clutch
Specifications Maximum Bore Size
11.75 in | 298 mm
Specifications Outer Diameter Length F
44.50 in | 1130 mm
Specifications Pilot Diameter B
16.5 in | 419 mm
Specifications Plt Thickness
1.61 in | 41 mm
